Specifications
Tower Type with CNC and Remote ControlAPI standard oil field pumping unit
Construction Hoist SC200/200
Payload: 2(t) x 2
Tower Type Pumping Unit
factory 0086 15290435825
Tower Type with CNC and Remote Control
Construction Hoist SC200/200
Payload: 2(t) x 2
Passengers: 20(person) x 2
Max Lifting height: 250m
Rated Lifting speed: 30m/min
Motor Power(kw): 11(kw)x3
Hoist Cage Dimension(m): 3x1.3x2.3m
Mast Section(mm): 650x650x1508mm
Safety Device: Model: SAJ4.0-1.2A
Brake Moment of Force(KN M): 40
We are Grade one regular supplier of SINOPEC
1. Detail technical datas
type |
kN |
stroke m |
Every minute pumping process m/min-1 |
Maximum drag torque kN·m |
WCYJTSK4-3-12-8Z |
40 |
≤3 |
≤12 |
8 |
WCYJTSK5-3-12-10Z |
50 |
≤3 |
≤12 |
10 |
WCYJTSK6-3-12-12Z |
60 |
≤3 |
≤12 |
12 |
WCYJTSK6-4.5-18-12Z |
60 |
≤4.5 |
≤18 |
12 |
WCYJTSK8-5-12-16Z |
80 |
≤5 |
≤12 |
16 |
WCYJTSK8-6-18-16Z |
80 |
≤6 |
≤18 |
16 |
WCYJTSK8-8-24-16Z |
80 |
≤8 |
≤24 |
16 |
WCYJTSK10-5-12-20Z |
100 |
≤5 |
≤12 |
20 |
WCYJTSK10-6-18-20Z |
100 |
≤6 |
≤18 |
20 |
WCYJTSK10-8-24-20Z |
100 |
≤8 |
≤24 |
20 |
WCYJTSK12-5-12-24Z |
120 |
≤5 |
≤12 |
24 |
WCYJTSK12-6-18-24Z |
120 |
≤6 |
≤18 |
24 |
WCYJTSK12-8-24-24Z |
120 |
≤8 |
≤24 |
24 |
WCYJTSK14-5-12-28Z |
140 |
≤5 |
≤12 |
28 |
WCYJTSK14-6-18-28Z |
140 |
≤6 |
≤18 |
28 |
WCYJTSK14-8-24-28Z |
140 |
≤8 |
≤24 |
28 |
WCYJTSK16-6-15-32Z |
160 |
≤6 |
≤15 |
32 |
WCYJTSK16-7-15-32Z |
160 |
≤7 |
≤15 |
32 |
WCYJTSK16-8-24-32Z |
160 |
≤8 |
≤24 |
32 |
WCYJTSK18-6-12-36Z |
180 |
≤6 |
≤12 |
36 |
WCYJTSK18-7-18-36Z |
180 |
≤7 |
≤18 |
36 |
WCYJTSK18-8-24-36Z |
180 |
≤8 |
≤24 |
36 |
WCYJTSK20-6-12-40Z |
200 |
≤6 |
≤12 |
40 |
WCYJTSK20-7-18-40Z |
200 |
≤7 |
≤18 |
40 |
WCYJTSK20-8-24-40Z |
200 |
≤8 |
≤24 |
40 |
WCYJTSK24-6-12-48Z |
240 |
≤6 |
≤12 |
48 |
WCYJTSK24-7-18-48Z |
240 |
≤7 |
≤18 |
48 |
WCYJTSK24-8-24-48Z |
240 |
≤8 |
≤24 |
48 |
2. Oilfield Site Pictures
