Long Stroke Energy Saving Pumping Unit
US$ 2,000 - 200,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
Zhongshi
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Long Stroke Energy Saving Pumping Unit FactoryUS$ 2,000 - 200,000MOQ: 1 Set -
Factory of API C Series Pumping UnitsUS$ 1,000 - 6,000MOQ: 1 Set
-
API 11E Standard Tower-type Long Stroke Energy Conservation Pumping Unit With Competitive PriceNegotiableMOQ: 1 Set
-
API C Series Beam Pumping Unit Energy Saving Pumping UnitNegotiableMOQ: 1 Set
-
APi Camber Beam Pumping Unit for Oilfield Oil Extraction Api Pump Unit Well Pump UnitNegotiableMOQ: 1 Set
Condition
New
Place of Origin
Henan, China
Brand Name
Zhongshi
Model Number
ZSCJ-series
Voltage
220V
Power(W)
55KW
Weight
30TON
Certification
ISO 9001
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Tower type pumping unit1. Stable working, long service life
2. High efficiency, energy saving
3. Long stroke, big load
Long stroke energy saving pumping unit
Description of our Long stroke Energy saving pumping unit :
- Reasonable structure, stable working, less noise,and easy to maintain.
- High efficiency, high safety.
- Long stoke, slow stroke frequency, big loading, intelligentized.
Advantage:
- Energy saving 40%.
- Pumping efficiency can raise 20%.
- Long stoke(1.5-9),stroke and frequency showing online.
- High explosion protection
- Easy to remove from well
- Less damage on rod&pump, long service life.
- Multi-safety protection.
- Touch screen dispay &operation, failure automatic alarm.
- Motor power factor:0.993.
- PLC central control available.
Parameter |
LSCY-12 |
LSCY-14 |
LSCY-16 |
LSCY-20 |
Stroke length |
6.0m |
7.3m |
7.3m |
7.3m |
Max load |
12t |
14t |
16t |
20t |
Max stroke frequency |
4 |
4 |
4 |
3 |
Min Stroke |
≤1m |
|||
Width of machine |
2.2m |
2.2m |
2.2m |
2.4 |
Height of machine |
10.5m |
11.18m |
11.18m |
11.18m |
Length(shipping) |
4.6m |
4.6m |
4.6m |
4.8m |
Weight(without balance weight) |
11t |
12.5t |
14.5t |
18.5t |
Working temperature |
-45-59°C |
|||
