API standard tubing pup joint
Specifications
pecifications
API oil Tubing pup joint .
Grade: API 5CT: J55,K55,M65,N80,L80,C90,T95,P110
other steel grade is available as per clients requirements.
Application: Generally for conveying gas and oil in both oil and natural gas industries
length: R2/R3
thread:BTC/LTC/STC
Product Name: EUE 5CT 2 3/8" PUP JOINT N80 (pipe fitting pup joint, pipe fitting)
Standard Reference: API spec 5CT
Size: 2 3/8" to 4-1/2''
Grade: J55, K55, N80-1, N80-Q, L80, C90, P110 N80
Type: NU, EU
Thread Type: Tubing round thread. Dimensions and their tolerances of tubing round-thread as per API spec 5B
Surface treatment: Coating
Protection of Thread: Thread protector
Packing: By wooden case, wooden pallet, or by the requirements of customers
Supply Ability: 20000 metric Ton per year
Payment Term: L/C, T/T
Descriptions and size |
Type of Thread |
O.D*L(mm) |
|
|
Tubing joint |
2-3/8" |
NUE |
73.02*107.95 |
2-3/8" |
EUE |
77.80*123.82 |
|
2-7/8" |
NUE |
88.90*130.18 |
|
2-7/8" |
EUE |
93.17*130.35 |
|
3-1/2" |
NUE |
107.95*142.88 |
|
3-1/2" |
EUE |
114.30*146.05 |
|
4" |
NUE |
120.65*146.05 |
|
4" |
EUE |
127.00*152.40 |
|
4-1/2" |
NUE |
132.08*155.58 |
|
4-1/2" |
EUE |
141.30*158.75 |
|
