API Drilling Rig for Oil Well

US$ 11,000 - 400,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Rotary Drilling Rig

Power Type:

Diesel

Puyang Zhongshi Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Rotary Drilling Rig

Power Type Diesel

Place of Origin Henan, China

Brand Name ZS

Model Number 2000HP

Certification API

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

API drilling rig for oil well

We are proud to be regular Grade 1 supplier for SINOPEC!

Drilling rig has four choice of driven mode according to your requirement:

A. mechanical driven,

B. combination driven,

C. DC motor driven,

D. AC stepless variable frequency driven.

ZJ-Drilling Rig

C-Truck Mounted T-Trailer Mounted L-Chain Drive

DB-Alternating Frequency Conversion Drive D-DC SCR driven

Drilling Rig technical datas:

Model	ZJ40/2250	ZJ50/3150	ZJ70/4500	ZJ90/5850	ZJ120/9000
Basic parameter (m)	4000	5000	7000	9000	12000
Nominal drilling depth,114mm drill pipe (m)	2500-4000	3500-5000	4500-7000	7000-9000	12000
Nominal drilling depth,127mm drill pipe (m)	2000-3200	2800-4500	4000-6000	6000-8000	8000-10000
Max. hook capacity (kN)	2250	3150	4500	6850	9000
Rated power of draw-works (Kw)	735	1100	1470	3000/4500	4500/6000
Number of drilling lines of travelling block	8	10	10	12	14
The max.number of wirelines of travelling block	10	12	12	14	16
The wireline dia. (mm)	32	35	38	45	45
Rated power of single drill pump (KW)	735/960	1180	1180	1180/1600	1600/2200
Open diameter of the rotary table	700	950	950	950/1257	1257
The height of drill floor (m)	7.5	910.5	910.5	10.512	10.512
