Help Center3D Motion Powder Mixer
Related Products
Specifications
Motion Powder Mixer3 directions move
Full closed
Whole SS
Larger loading capacity, short mixing time and high efficiency
3D Motion Powder Mixer
We can supply a complete set according to the users' requirments.
Working Principle:
This machine is composed of base, governor motor shaft, rotary connecting rod and barrel etc.. The material barrel is driven by the positive shaft to make complex movement including horizontal move, rotation and rolling etc., which make the material move in 3 directions along the barrel, therefore, highly uniform mixing of various material is realized.
This machine is a kind of full closed high effcient energy saving mixer without germ and dust. When the material is being mixed, no centrifugal force effect or situation of gravity segregation or laminar accumulation occur. In addition, it has large loading capacity, short mixing time and high efficiency
Technical Parameters :
Item |
SWH-100 |
SWH-200 |
SWH-400 |
SWH- 600 |
SWH- 800 |
SWH-1000 |
SWH-1200 |
SWH-1500 |
Barrel volume (L) |
100 |
200 |
400 |
600 |
800 |
1000 |
1200 |
1500 |
Max loading volume(L) |
75 |
160 |
320 |
480 |
640 |
800 |
950 |
1200 |
Max loading weight(kg) |
75 |
160 |
320 |
480 |
640 |
800 |
950 |
1200 |
Spindle speed(r/min) |
0-15 |
0-15 |
0-15 |
0-15 |
0-15 |
0-15 |
0-15 |
0-15 |
Motor power(kw) |
1.5 |
2.2 |
4 |
5.5 |
7.5 |
7.5 |
11 |
15 |
Overall dimension (mm) |
1200*1700 |
1400*1800 |
1800*2100 |
1900*2100 |
2200*2400 |
2250*2600 |
2400*2800 |
2500*2950 |
Weight(kg) |
500 |
800 |
1200 |
1500 |
2000 |
2500 |
2800 |
3000 |
Customer Service
Our excellent customer service also includes the installation of our machines. To ensure smooth performance, we also provide a one year warranty, and a spare set of wearing parts to our customers. If any difficulty occurs, we will supply free spare parts and even on-site service, upon request.
Please contact us to help you with your particular pharmacy equipment needs.
