Specifications
Filling and sealing machineAutomatically controlled by PLC
Meet cGMP
Frequency conversion speed
Economical type
THG Series Automatic Liquid Filling and Sealing Machine
We can supply a complete set according to the users' requirments.
Machine this department our company draw lessons from foreign advanced technology, a new generation that develops by oneself irritates installation. This machine adopts the piston to measure,
collect the electro mechanics, pneumatic in an organic whole, Controlled by PLC, the structure is
compact, designs rationally, fill into accurately, and operate the characteristic such as being
reliable, work and with high efficiency, longer-lived steadily. Extensively suitable for fill into, can fill
into various kinds of liquid , glue the thick body etc. It can used for various kinds of semi fluid,
lotion, sauced material including particle, have a lot of kinds of pouring into amount at your choice.
Other Characteristic:
1).It is that the stainless steel is made to contact with the supplies, totally accord with GMP standard;
2).Living and taking over fast, it is simple and swift to unpick and wash;
3).The filling speed convenient to be adjustable, change different bottles like specification, do not
need to change the part , adjust it easily;
4).There is the leak protection device to fill into the head, does not have wire drawing, water clock to
irritate the form definitely .
Main Technical parameters
Capacity: 20-50 pcs/min
Filling station 4 heads
Capping head: one
Applied for 30-150ml
Filling tolerance ±1%
Qualified Cap putting : ≥98%
Qualified Capping: ≥98%
Speed control: By inverter
Power supply: 380V 50Hz/60Hz
Total power: 1.8KW
Outside dimension: 3000×900×1700mm
Customer Service
Our excellent customer service also includes the installation of our machines. To ensure smooth performance, we also provide a one year warranty, and a spare set of wearing parts to our customers. If
any difficulty occurs, we will supply free spare parts and even on-site service, upon request.
Please contact us to help you with your particular pharmacy equipment needs.
