Ultrahigh frequency induction melting machine
- 100 Set / Sets per Month
- NINGBO/SHANGHAI
- T/T
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Jotun JT-SDJ Industrial Automatic Metal Sheet Surface Polishing Machine
- Large Metal Sheet Metal Workpiece Processing Deburring Chamfering Plane Belt Polishing Machine
- Heavy Duty Automatic Wide Belt Metal Sand Deburring Machine
- Metal Plate Deburring and Rust Removal Machine Steel Plate Sand Belt Drawing and Polishing Equipment Flat Polishing Machine
- Metal Flat Sheet Laser Cutting Parts Deburring Grinding Polishing Machine Manufacturer
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | YUELON | Model Number: | UF-03AB |
After-sales Service Provided: | No overseas service provided |
Product Description
Yuelon is specialized in researching and manufacturing of solid-state medium to ultrahigh frequency induction
heating equipment and systems. our company was established in 1998 and is privately held. Precision
induction heating solutions are our specialty. Use induction heating to improve the efficiency and effectivenes for industrial heating process. That are used for application such as brazing. annealing,hardening, forging,
melting, shrink fitting etc.
Our induction heating machine are Available from 3kw to 1500kw deliverable output power with 0.5KHZ to1.1
MHZ operating frequency range. All our products are divided into four major series according to
the frequency:
Medium frequency series (abbr. MF series):0.2-20KHZ
High frequency series (abbr. HF series):30-100KHZ
Superaudio frequency series (abbr. SF series):5-40KHZ
Ultrahigh frequency series (abbr. UF series):100-1100KHZ
UF-04A/AB
Main specifications:
Maximum oscillating power: 3KVA
Maximum input power: 3KW
Oscillating frequency: 500-1100KHZ
Heating current:200-400A
Maximum input current: 14A
Input voltage: 220VAC single phases, 50 or 60Hz
Duty cycle: 80%
Cooling water: ≥0.2Mpa 2L/min
Auto heating time: 0.1-9.9seconds
Auto retaining time: 0.1-9.9seconds
Auto cooling time: 0.1-9.9seconds
Weight and dimension:
Model | Net weight(KG) | Size: L x W x H (mm) | Packing weight | Pacing size: L x W x H (mm) |
UF-03AB generator | 18KG | 450x240x300mm | 52KG | 550x480x400mm |
UF-03AB transformer | 4KG | 140x140x93mm |
Main models and specifications:
Models | Maximum input power | Oscillating frequency | Maximum input current | Input voltage | Duty cycle |
UF-04A | 4KW | 100-250KHZ | 15A | Single phase 220V | 80% |
UF-03AB | 3KW | 0.5-1.1MHZ | 14A | Single phase 220V | 80% |
UF-06A-I | 6.6KW | 200-500KHZ | 27A | Single phase 220V | 80% |
UF-06A-II | 200-700KHZ | ||||
UF-06A-III | 0.5-1.1MHZ | ||||
UF-10A-I | 10KW | 50-300KHZ | 15A | 3phase 380V | 100% |
UF-10A-II | 10KW | 200-500KHZ | 15A | Single phase 220V | 80% |
UF-20AB | 20KW | 50-250KHZ | 30A | 3phase 380V | 100% |
UF-30AB | 30KW | 50-200KHZ | 45A | 3phase 380V | 100% |
UF-40AB | 40KW | 50-200KHZ | 60A | 3phase 80V | 100% |
UF-60AB | 60KW | 30-150KHZ | 90A | 3phase 380V | 100% |
UF-100AB | 100KW | 30-150KHZ | 150A | 3phase 380V | 100% |
UF-160AB | 160KW | 30-120KHZ | 240A | 3phase 380V | 100% |
machine can be protected from destroys and machines can be repaired easily.
> light weight, small size.
> different shape and size of induction coil can be changed easily to heat different parts.
> advantages of the model with timer: the power and the operating time of the heating period and retain period can be
preset respectively, to realize a simple heating curve,this model is suggested to use for batch production to improve the
repeatability.
> the separated models are designed to fit the dirty surroundings, the generator can be put in a clean space to increase
the reliability; with the small size and light weight ofthe separated transformer, it is conveient to use in the production line
and easily assembled inside the machinery or moved mechanism.
