YONGKANG YUELON ELECTRONIC EQUIPMENT CO.,LTD
YUELON is specialized in researching and manufacturing of solid-state medium to ultrahigh frequency induction heating equipment and systems.
Our company was established in 1998 and is privately held.
Precision induction heating solutions are our specialty. Use induction heating to improve the efficiency and effectiveness for industrial heating
process. that are used for application such as brazing, annealing, quenching, forging, melting, shrink fitting etc.
our induction heating machine are Available from 2KW to 1500KW deliverable output power with 0.5KHZ to 1.1MHZ operating frequency range.
All our products are divided into four major series according to the frequency:
Medium frequency series (abbr. MF series): 0.2-20KHZ
High frequency series (abbr. HF series): 30-100KHZ
Superaudio frequency series (abbr. SF series): 8-40KHZ
Ultrahigh frequency series (abbr. UF series) : 100-1000KHZ
UF-40AB
Main specifications:
Maximum input power: 40KW
Oscillating frequency: 50-200KHz
Maximum input current: 60A
Input voltage: 3phases 380VAC, 50 or 60Hz
Duty cycle: 100%
Cooling water: ≥0.2Mpa 6L/min
Auto heating time: 0.1-99.9seconds
Auto retaining time: 0.1-99.9seconds
Auto cooling time: 0.1-99.9seconds
Generator Weight: 32KG
Generator size: 640x350x550mm
Transformer weight:25KG
Transformer size: 510x300x450mm
Packing weight: 96KG
Packing size: 750x750x650mm
Main characteristics:
- With high frequency up to 120KHZ , and very thin and tiny parts can be easily heated.
- IGBT and current inverting technologies have been used; higher reliability and lower maintenace cost.
- 100% duty cycle, continuous working is allowed at maximum power output.
- Constant current or constant power status can be selected accordingly to achieve higher heating efficiency;
- Display of heating power and heating current and oscillating frequency.
- Simple to install , installation can be done by unprofessional person very easily;
- Light weight, small size;
- different shape and size of induction coil can be changed easily to heat different parts.
- Advantages of the model with timer: the power and the operating time of the heating period and the retain period can be
preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability.
Main applications:
Quenching of shaft
Quenching of gear
Brazing of copper bars
Heating of bullet shell
Floating melt with water cooled crucible
Annealing of wire continuously
Etc.
Main models and specifications:
Models |
Maximum input power |
Oscillating frequency |
Maximum input current |
Input voltage |
Duty cycle |
UF-04A |
4KW |
100-250KHZ |
15A |
Single phase 220V |
80% |
UF-03AB |
3KW |
0.5-1.1MHZ |
14A |
Single phase 220V |
80% |
UF-06A-I |
6.6KW |
200-500KHZ |
27A |
Single phase 220V |
80% |
UF-06A-II |
200-700KHZ |
||||
UF-06A-III |
0.5-1.1MHZ |
||||
UF-10A-I |
10KW |
50-300KHZ |
15A |
3phase 380V |
100% |
UF-10A-II |
10KW |
200-500KHZ |
15A |
Single phase 220V |
80% |
UF-20AB |
20KW |
50-250KHZ |
30A |
3phase 380V |
100% |
UF-30AB |
30KW |
50-200KHZ |
45A |
3phase 380V |
100% |
UF-40AB |
40KW |
50-200KHZ |
60A |
3phase 80V |
100% |
UF-60AB |
60KW |
30-150KHZ |
90A |
3phase 380V |
100% |
UF-100AB |
100KW |
30-150KHZ |
150A |
3phase 380V |
100% |
UF-160AB |
160KW |
30-120KHZ |
240A |
3phase 380V |
100% |
We offer complete service :
Before sales
Machine have one year quality warranty ,0ne year free replacement spare parts ( 1 set of spare parts free for your stock, in case it need replacement).
...
