Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > High Frequency Induction Heating Machine 100KW

High Frequency Induction Heating Machine 100KW

Name: High Frequency Induction Heating Machine 100KW
Brand: YUELON
SKU: 130284499
Availability: InStock

High Frequency Induction Heating Machine 100KW thumbnail-1

High Frequency Induction Heating Machine 100KW photo-1

US$ 16,000 - 18,000 MOQ: 1 Unit

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

YUELON

Model Number:

UF100

Contact Supplier Request Quote Chat Now

Yongkang Yuelon Electronic Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo or shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name YUELON

Model Number UF100

Input Voltage 380V

Output Voltage 48V

Output Power 100KW

Output Frequency 30-150KHz

Output Current 150A

UF-100AB

Main specifications:

Maximum input power: 100KW

Oscillating frequency: 30-150KHz

Maximum input current: 150A

Input voltage: 3phases 380VAC, 50 or 60Hz

Duty cycle: 100%

Cooling water: ≥0.2Mpa 10L/min

Auto heating time: 0.1-99.9seconds

Auto retaining time: 0.1-99.9seconds

Auto cooling time: 0.1-99.9seconds

Generator Weight: 94KG

Generator size: 760x400x880mm

Transformer weight:28KG

Transformer size: 510x300x450mm

Packing weight: 182KG

Packing size: 880x820x990mm

Main characteristics:

With high frequency up to 150KHZ , and very thin and tiny parts can be easily heated.
IGBT and current inverting technologies have been used; higher reliability and lower maintenace cost.
100% duty cycle, continuous working is allowed at maximum power output.
Constant current or constant power status can be selected accordingly to achieve higher heating efficiency;
Display of heating power and heating current and oscillating frequency.
Simple to install , installation can be done by unprofessional person very easily;
Light weight, small size;
different shape and size of induction coil can be changed easily to heat different parts.
Advantages of the model with timer: the power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability.

Main applications:

Quenching of shaft

Quenching of gear

Brazing of copper bars

Heating of bullet shell

Floating melt with water cooled crucible

Annealing of wire continuously

Etc.

...
