Cookware composite pot bottom brazing machine / cookware sandwich bottom brazing machine for pan, pot, kettle
Cookware pan bottom induction brazing machine is mainly used for cookware compound bottom welding of stainless steel pan, pot, kettle, and also can be used for plane heating of other workpiece. Cookware Pan and pot bottom brazing machine is an mechanical, hydraulic and electrical integrated equipment controlled by several sets microcomputer. The main performance index takes the leading position at home and aboard.
According to the difference of heating power supply and welding diameters, this cookware sandwich bottom induction brazing equipment can be divided into a variety of models, such as:
A. Transistor high frequency cookware bottom brazing machine
Features:
1. Using high power transistor, safety and reliability, energy saving.
2. Uniform heating and good welding quality.
3. Fast heating speed and high production rate.
4. Digital display of operating mode, simple operation and easy maintenance.
Power: 50KW, 80KW, 100KW
Frequency: 200-300KHz
Welding diameter: 100-500mm
B. Vacuum tube high frequency brazing machine
Features:
1. Using traditional vacuum tube, the technology is mature and reliable.
2. Fast heating speed and high production efficiency.
3. The overall design is reasonable, small heat loss, and beautiful appearance.
4. Internal pressurizer, low price and small investment.
5. Digital display of operating mode and easy maintenance
Power: 60KW, 100KW, 150KW
Frequency: 200-300KHz
Welding diameter: 100-500mm
Main models and specifications:
Model |
Power supply |
description |
Rated power |
Max welding diameter |
Size L x W x H mm |
V-21-60kw/280 |
Vacuum tube |
Single heating head double station |
60KW |
280mm |
2450 x 3100 x 2000mm |
V-22-100kw/240 |
Vacuum tube |
Double heating head double station |
100KW |
240mm |
2450 x 3100 x 2000mm |
V-21-150kw/500 |
Vacuum tube |
Single heating head double station |
150KW |
500mm |
2650 x 3100 x 2000mm |
T-11-50kw/280 |
Transistor |
Single heating head single station |
50KW |
280mm |
1350 x 3100 x 2000mm |
T-21-50kw/280 |
Transistor |
Single heating head double station |
50KW |
280mm |
2450 x 3100 x 2000mm |
T-21-80kw/340 |
Transistor |
Single heating head double station |
80KW |
340mm |
2650 x 3100 x 2000mm |
T-21-100kw/360 |
Transistor |
Single heating head double station |
100KW |
360mm |
2650 x 3100 x 2000mm |
Yuelon is specialized in researching and manufacturing of solid-state medium to ultrahigh frequency induction
heating equipment and systems. our company was established in 1998 and is privately held. Precision
induction heating solutions are our specialty. Use induction heating to improve the efficiency and
effectivenesfor industrial heating process. That are used for application such as brazing. annealing,hardening,
forging, melting, shrink fitting etc.
Our induction heating machine are Available from 3kw to 1500kw deliverable output power with 0.5KHZ to1.1M
HZ operating frequency range. All our products are divided into four major series according to the frequency:
Medium frequency series (abbr. MF series):0.2-20KHZ
High frequency series (abbr. HF series):30-100KHZ
Superaudio frequency series (abbr. SF series):5-40KHZ
Ultrahigh frequency series (abbr. UF series):100-1100KHZ
