Help CenterTri-ply Sandwich Bottom Cookware Brazing Machine
Related Products
-
Composite Pan Bottom Heating MachineNegotiableMOQ: 1 Set -
Cookware Bottom Induction Heating MachineNegotiableMOQ: 1 Set
-
High Frequency Cookware Utensil Bottom Induction Brazing MachineNegotiableMOQ: 1 Set
-
Cookware Sandwich Capsule Bottom Induction Brazing MachineNegotiableMOQ: 1 Set
-
Cookware Sandwish Bottom Induction Brazing MachineNegotiableMOQ: 1 Set
We provide high quality induction brazing machine to welding stainless steel plate, aluminum sheet and heating element into one whole body at one time for electric heating pan, pot, kettle as per the requirements of the clients with multi heating station.
High power electron tube high frequency power supply is used as the heating power supply, and the hydraulic system is used as drive force. The running is stable, control is precise, operation is simple and product up-to-standard rate is high. The PLC control is adopted to realize functions such as automatic counting, automatic timing, heat quantity control and technical process programming, making it the best equipment for the production of the new generation of electro-heating stainless steel kitchen utensils.
Main specifications:
Cookware composite pot bottom brazing machine / cookware sandwich bottom brazing machine for pan, pot, kettle
Cookware pan bottom induction brazing machine is mainly used for cookware compound bottom welding of stainless steel pan, pot, kettle, and also can be used for plane heating of other workpiece. Cookware Pan and pot bottom brazing machine is an mechanical, hydraulic and electrical integrated equipment controlled by several sets microcomputer. The main performance index takes the leading position at home and aboard.
According to the difference of heating power supply and welding diameters, this cookware sandwich bottom induction brazing equipment can be divided into a variety of models, such as:
Model |
Power supply |
description |
Rated power |
Max welding diameter |
Size L x W x H mm |
V-21-60kw/280 |
Vacuum tube |
Single heating head double station |
60KW |
280mm |
2450 x 3100 x 2000mm |
V-22-100kw/240 |
Vacuum tube |
Double heating head double station |
100KW |
240mm |
2450 x 3100 x 2000mm |
V-21-150kw/500 |
Vacuum tube |
Single heating head double station |
150KW |
500mm |
2650 x 3100 x 2000mm |
T-11-50kw/280 |
Transistor |
Single heating head single station |
50KW |
280mm |
1350 x 3100 x 2000mm |
T-21-50kw/280 |
Transistor |
Single heating head double station |
50KW |
280mm |
2450 x 3100 x 2000mm |
T-21-80kw/340 |
Transistor |
Single heating head double station |
80KW |
340mm |
2650 x 3100 x 2000mm |
T-21-100kw/360 |
Transistor |
Single heating head double station |
100KW |
360mm |
2650 x 3100 x 2000mm |
Yuelon is specialized in researching and manufacturing of solid-state medium to ultrahigh frequency induction
heating equipment and systems. our company was established in 1998 and is privately held. Precision
induction heating solutions are our specialty. Use induction heating to improve the efficiency and
effectivenesfor industrial heating process. That are used for application such as brazing. annealing,hardening,
forging, melting, shrink fitting etc.
Our induction heating machine are Available from 3kw to 1500kw deliverable output power with 0.5KHZ to1.1M
HZ operating frequency range. All our products are divided into four major series according to the frequency:
Medium frequency series (abbr. MF series):0.2-20KHZ
High frequency series (abbr. HF series):30-100KHZ
Superaudio frequency series (abbr. SF series):5-40KHZ
Ultrahigh frequency series (abbr. UF series):100-1100KHZ
