Induction Brazing Machine for Cookware

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Model Number:

V-22-100kw/240

After-sales Service Provided:

Engineers available to service machinery overseas

Yongkang Yuelon Electronic Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo/shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Model Number V-22-100kw/240

After-sales Service Provided Engineers available to service machinery overseas

Company Information

Yuelon is specialized in researching and manufacturing of solid-state medium to ultrahigh frequency induction

heating equipment and systems. our company was established in 1998 and is privately held. Precision

induction heating solutions are our specialty. Use induction heating to improve the efficiency and

effectivenesfor industrial heating process. That are used for application such as brazing. annealing,hardening,

forging, melting, shrink fitting etc.

Our induction heating machine are Available from 3kw to 1500kw deliverable output power with 0.5KHZ to1.1M

HZ operating frequency range. All our products are divided into four major series according to the frequency:

Medium frequency series (abbr. MF series):0.2-20KHZ

High frequency series (abbr. HF series):30-100KHZ

Superaudio frequency series (abbr. SF series):5-40KHZ

Ultrahigh frequency series (abbr. UF series):100-1100KHZ

Main models and specifications:

Model	Power supply	description	Rated power	Max welding diameter	Size L x W x H mm
V-21-60kw/280	Vacuum tube	Single heating head double station	60KW	280mm	2450 x 3100 x 2000mm
V-22-100kw/240	Vacuum tube	Double heating head double station	100KW	240mm	2450 x 3100 x 2000mm
V-21-150kw/500	Vacuum tube	Single heating head double station	150KW	500mm	2650 x 3100 x 2000mm
T-11-50kw/280	Transistor	Single heating head single station	50KW	280mm	1350 x 3100 x 2000mm
T-21-50kw/280	Transistor	Single heating head double station	50KW	280mm	2450 x 3100 x 2000mm
T-21-80kw/340	Transistor	Single heating head double station	80KW	340mm	2650 x 3100 x 2000mm
T-21-100kw/360	Transistor	Single heating head double station	100KW	360mm	2650 x 3100 x 2000mm
