Yuelon is specialized in researching and manufacturing of solid-state medium to ultrahigh frequency induction
heating equipment and systems. our company was established in 1998 and is privately held. Precision
induction heating solutions are our specialty. Use induction heating to improve the efficiency and effectivenes for industrial heating process. That are used for application such as brazing. annealing,hardening, forging,
melting, shrink fitting etc.
Our induction heating machine are Available from 3kw to 1500kw deliverable output power with 0.5KHZ to1.1
MHZ operating frequency range. All our products are divided into four major series according to
the frequency:
Medium frequency series (abbr. MF series):0.2-20KHZ
High frequency series (abbr. HF series):30-100KHZ
Superaudio frequency series (abbr. SF series):5-40KHZ
Ultrahigh frequency series (abbr. UF series):100-1100KHZ
>MOSFET power component and current inverting technologies have been used.
>simple structure and light weight.
> simple to operate, a few minutes is enough to learn it.
> simple to install, installation can be donne by unprofesstional person very easily.
> multidisplay functions, with displays of over current, over voltage, water failure, phase failure and unfit lad and so on,
machine can be protected from destroys and machines can be repaired easily.
> light weight, small size.
> different shape and size of induction coil can be changed easily to heat different parts.
> advantages of the model with timer: the power and the operating time of the heating period and retain period can be
preset respectively, to realize a simple heating curve,this model is suggested to use for batch production to improve the
repeatability.
> the separated models are designed to fit the dirty surroundings, the generator can be put in a clean space to increase
the reliability; with the small size and light weight ofthe separated transformer, it is conveient to use in the production line
and easily assembled inside the machinery or moved mechanism.
Model |
Maximum input power |
Oscillating frequency |
Max input current |
Input voltage |
Duty cycle |
HF-15A/AB |
7KW |
30-100KHz |
32A |
Single phase 220V 50Hz |
80% |
HF-25A/AB |
15KW |
30-80KHz |
23A |
3phase 380V 50Hz |
100 |
HF-25ABD |
25KW |
30-80KHz |
38A |
3phase 380V 50Hz |
100% |
HF-35AB |
35KW |
30-80KHz |
55A |
3phase 380V 50Hz |
100% |
HF-45AB |
45KW |
30-80KHz |
68A |
3phase 380V 50Hz |
100% |
HF-70AB |
70KW |
30-80KHz |
105A |
3phase 380V 50Hz |
100% |
We offer complete service :
Before sales
Machine have one year quality warranty ,0ne year free replacement spare parts ( 1 set of spare parts free for your stock, in case it need replacement).
...
