The main features of frequency power supply
1.With IGBT power devices and variable flow control technology, the use of the parallel resonant circuit.
2.Frequency range, from 1KHZ-20KHZ, can be matched according to the size of the specific heat of the work piece or the depth
of penetration of heat required to adapt to a wide range.
3.Medium frequency traditional parallel resonant structure, load matching simple, high efficiency and high utilization of
equipment.
4.Using inverter control technology, all soft switching precision control, high equipment reliability, low maintenance.
5.Small, customers save 10 times the production space.
6.Energy efficient, the whole power range, high power factor and power efficiency;
7.Broadband 1-20KHZ frequency automatic tracking ability to adapt without on-site commissioning;
8.100% duty cycle, 24 hours of continuous work capacity.
9.Constant output voltage / constant output power control selection function;
10.Frequency, power, voltage and current of the whole show;
11.Simple operation, a few minutes to learn.
12.Installation is simple, connected three 380V and cooling water can be.
13.Selectable timer set independently adjust each heating time, heating power, holding time, holding the power to control
the heating curve of the heating temperature.
Medium frequency power of the main models
Models |
Rated output power |
Frequency rage |
Input current |
Input voltage |
Duty cycle |
Water flow |
weight |
Dimension |
MFS-100 |
100KW |
0.5-10KHz |
160A |
3phase 380V 50Hz |
100% |
10-20m3/h |
180KG |
620x680x1630mm |
MFS-160 |
160KW |
0.5-10KHz |
260A |
10-20m3/h |
220KG |
720x 780 x 1800mm |
||
MFS-200 |
200KW |
0.5-10KHz |
330A |
10-20m3/h |
230KG |
820x 780 x 1800mm |
||
MFS-250 |
250KW |
0.5-10KHz |
400A |
10-20m3/h |
245KG |
820x 780 x 1800mm |
||
MFS-300 |
300KW |
0.5-8KHz |
500A |
25-35m3/h |
350KG |
920x 930 x 1950mm |
||
MFS-400 |
400KW |
0.5-8KHz |
670A |
25-35m3/h |
360KG |
920x 930 x 2080mm |
||
MFS-500 |
500KW |
0.5-8KHz |
750A |
25-35m3/h |
600KG |
1500 x 800 x 2000mm |
||
MFS-600 |
600KW |
0.5-8KHz |
1000A |
25-35m3/h |
620KG |
1500 x 800 x 2000mm |
||
MFS-750 |
750KW |
0.5-6KHz |
1300A |
50-60m3/h |
630KG |
1500 x 800 x 2000mm |
||
MFS-800 |
800KW |
0.5-6KHz |
1500A |
50-60m3/h |
650KG |
1500 x 800 x 2000mm |
||
MFS-1200 |
1200KW |
0.2-4KHz |
2000A |
50-60m3/h |
920KG |
2500x1000 x 2000mm |
||
MFS-1500 |
1500KW |
0.2-4KHz |
2500A |
50-60m3/h |
1020KG |
2500x1000 x 2000mm |
