Specifications
PCI 3G/HSDPA MODEM1. Based on Simcom module SIM5210
2. TCP/IP stack
3. UMTS 2100MHZ, GSM quad-band
4. HSDPA: 7.2Mbps
PCI 3G/HSDPA MODEM
Product description:
General features:
Industrial design
Based on Simcom module SIM5210
UMTS/WCDMA/HSDPA: 2100MHZ
GSM/GPRS/EDGE:850/900/1800/1900MHZ
GPRS class 12
EDGE class 12
UMTS/HSDPA 3GPP release 5
GSM 3GPP release 99
3V SIM card slot
PCI interface
Internet, data and SMS service
Output Power
Class 42W @850/ 900MHz
Class 11W @ 1800/1900MHz
Class 3 (0.25W@2100MHZ)
Input voltage5V-
Input current1A-2A
Standby current: 56mA
Working current: 100-140mA
Working temperature -20 to+55 degrees
Storage temperature: -25 to+70 degrees
Size120*62*2mm
Weight65g
Accessories: antenna, CD
Packing: 1pc/white box,
30pcs/carton(42x22x51cm)/7kg
Spec for Data transfer:
HSDPA: Max. 7.2Mbps (DL)
UE Category: 6, 8, 12
WCDMA: Max. 384 Kbps (DL), Max.384Kbps (UL)
EDGE: Max. 236. 8 Kbps (DL),Max118 Kbps (UL)
GPRS: Max. 85.6 Kbps (DL), Max.42.8 Kbps (UL)
CSD: GSM Data rate 14.4Kbps,
WCDMA date rate 57.6Kbps
Spec for SMS
Point to point MO and MT
SMS Cell broadcast
Text and PDU mode
