Help CenterWavecom GPRS MODULE
Related Products
Specifications
1.Wavecom Q2438J CDMA MODULE2.DUAL-BAND800/1900MHZ
3.Wireless Interface
4.GOOD QUALITY
CDMA MODULE
DUAL-BAND800/1900MHZ
Wireless Interface
· CDMA2000 1XRTT (IS-2000) - (Dual Band)
· Band class 0 (TX: 824 ~ 849 MHz/ RX: 869 ~ 894 MHz)
· Band class 1 (TX: 1850 ~ 1910 MHz/ RX: 1930 ~ 1990 MHz)
· Data rates up to 153 kbps forward and reverse
Hardware
·Operating Voltage: 3.8 V to 4.2 V (3.7 nominal)
·Output Power: 0.63W AMPS; 0.35W CDMA
·Current consumption:
·4 mA (in Sleep Mode),
·Up to 670 mA (PCS Rx/Tx full Power)
·Differential Audio
1) ringer / buzzer output
2) Analog audio (microphone + speaker)
·PCM Audio Interface
·USB (population option); external transceiver required
·Up to 2 serial UARTS
·USB (external transceiver required)
·3V with R-UIM detection (5V with external level shifter)
·Power supply
·Keypad (5x5 matrix)
·ADC
·31 GPIO
