(Blue / yellow / green/white screen black colour 12832F 128*32 Dots 3.5V or 5V) LCD Screen Module
USD $1 - $4
/ Piece
1 Piece(Min.Order)
- 10000 Piece / Pieces per Month
- Shenzhen
- Credit Card PayPal
You May Like
- negative segment character running machine lcd display,practical STN,blue backlight, fitness equipment
- digital fire alarm installation module display, HTN segment display with blue led lcd panel
- negative autoreclose circuit-breaker lcd display, segment module with blue led
- charger negative character lcd display,white led ,battery segment small flexible display
- character small charger lcd display ,custom battery display ,white led
- segment positive temperature time clock lcd display,blue TN white backlight
Product Details
Brand Name: | SSS | Model Number: | 12832F | Type: | Character |
Product Description
(Blue / yellow / green/white screen black colour 12832F 128*32 Dots 3.5V or 5V) LCD Screen Module
What is Specifications of our 128x32 lcd module ?
Product Type: BYT12832F
Dot matrix: 128 × 32
Dimensions: 80.5 × 43.0 × 13.0
Sight size: 60.0 × 18.0
Point size: 0.35 × 0.40
Point spacing: 0.40 × 0.45
Display Mode: STN (green, blue, gray) mode, FSTN monochrome mode
Display Angle: 6:00 view
Control chip: ST7920 and compatible
Operating voltage: +5 V / +3.3 V
Working temperature: -20 °C ~ 70 °C
Storage temperature: -30 °C ~ 80 °C
Functions and Features
BYT12832 is a graphic dot matrix LCD modules. It mainly consists of row and column drivers drive components, can display 128 (columns) × 32 (OK) lattice. Complete graphical display can also display 8 × 2 pcs (16 × 16 dot matrix) characters. Seven control instruction, the CPU data bus interface uses 8 parallel input and output. Standard operating voltage of +5.0 V, when using VDD = +3.3 V, the need to factory settings; Meanwhile, according to customer needs, a variety of customized LCD modules.
Electrical parameters
Item Symbol Test Conditions Typical Units
Operating voltage VDD Ta = 25 °C 5.0 V
Operating Current IDD Ta = 25 °C, VDD = 5.0V 1.3 mA
Dot matrix: 128 × 32
Dimensions: 80.5 × 43.0 × 13.0
Sight size: 60.0 × 18.0
Point size: 0.35 × 0.40
Point spacing: 0.40 × 0.45
Display Mode: STN (green, blue, gray) mode, FSTN monochrome mode
Display Angle: 6:00 view
Control chip: ST7920 and compatible
Operating voltage: +5 V / +3.3 V
Working temperature: -20 °C ~ 70 °C
Storage temperature: -30 °C ~ 80 °C
Functions and Features
BYT12832 is a graphic dot matrix LCD modules. It mainly consists of row and column drivers drive components, can display 128 (columns) × 32 (OK) lattice. Complete graphical display can also display 8 × 2 pcs (16 × 16 dot matrix) characters. Seven control instruction, the CPU data bus interface uses 8 parallel input and output. Standard operating voltage of +5.0 V, when using VDD = +3.3 V, the need to factory settings; Meanwhile, according to customer needs, a variety of customized LCD modules.
Electrical parameters
Item Symbol Test Conditions Typical Units
Operating voltage VDD Ta = 25 °C 5.0 V
Operating Current IDD Ta = 25 °C, VDD = 5.0V 1.3 mA
What is Advantages of our 128x32 lcd module ?
- Competitive factory price.
- Professional purchase team to serve you.
- All our productions are checked by QC before shipping.
What is Refund & Replacement of our 128x32 lcd module ?
- We provide 30 days warranty for brand new goods only.
- If the item you purchase from us are not same as we promised, that is they don't work to manufacturers specifications, model mistake, simply return them to us for replacement or refund.
- If the items is defective, pls notify us within 3 working days on receiving it.
- Our sales representative will be here always serve for you.
