Home > Products > Modules > Blue / yellow / green/white screen black colour 12832F 128*32 Dots 3.3V or 5V LCD Screen Module
Blue / yellow / green/white screen black colour 12832F 128*32 Dots 3.3V or 5V LCD Screen Module
USD $4 - $6
/ Piece
1 Piece(Min.Order)
- 10000 Piece / Pieces per Month
- Shenzhen
- Credit Card PayPal
You May Like
-
12832F 128*32 Dots st7920 main chip LCD display Module
-
Built-in industry standard HD44780 equivalent LCD controller display 1602 module lcd 16x2
-
(Hot Offer)Mini USB 5V 1A Lithium Battery Charging Board Module
-
A 0-40 Mhz AD9850 DDS SIGNAL GENERATOR MODULE , 2 SINE & 2 SQUARE WAVEDDS Signal Generator Module
-
A 0-40 Mhz 2 SINE & 2 SQUARE WAVE ad9851 dds signal generator module
-
Original factory wholesale price HCSR04 Ultrasonic Wave Detector Ranging Module Distance Sensor HC-SR04
Product Details
Brand Name | SSS | Model Number | 12832F | |
Type | Character |
Product Description
Specifications
1,Original New LCD Module2,128*32 Dots
3,Made in China
4,Fast Shipping
5,CE&RoHS
Blue / yellow / green/white screen black colour 12832F 128*32 Dots 3.3V or 5V LCD Screen Module
What is Specifications of our 3.3v lcd module ?
Product Type: BYT12832F
Dot matrix: 128 × 32
Dimensions: 80.5 × 43.0 × 13.0
Sight size: 60.0 × 18.0
Point size: 0.35 × 0.40
Point spacing: 0.40 × 0.45
Display Mode: STN (green, blue, gray) mode, FSTN monochrome mode
Display Angle: 6:00 view
Control chip: ST7920 and compatible
Operating voltage: +5 V / +3.3 V
Working temperature: -20 °C ~ 70 °C
Storage temperature: -30 °C ~ 80 °C
Functions and Features
BYT12832 is a graphic dot matrix LCD modules. It mainly consists of row and column drivers drive components, can display 128 (columns) × 32 (OK) lattice. Complete graphical display can also display 8 × 2 pcs (16 × 16 dot matrix) characters. Seven control instruction, the CPU data bus interface uses 8 parallel input and output. Standard operating voltage of +5.0 V, when using VDD = +3.3 V, the need to factory settings; Meanwhile, according to customer needs, a variety of customized LCD modules.
Electrical parameters
Item Symbol Test Conditions Typical Units
Operating voltage VDD Ta = 25 °C 5.0 V
Operating Current IDD Ta = 25 °C, VDD = 5.0V 1.3 mA
Dot matrix: 128 × 32
Dimensions: 80.5 × 43.0 × 13.0
Sight size: 60.0 × 18.0
Point size: 0.35 × 0.40
Point spacing: 0.40 × 0.45
Display Mode: STN (green, blue, gray) mode, FSTN monochrome mode
Display Angle: 6:00 view
Control chip: ST7920 and compatible
Operating voltage: +5 V / +3.3 V
Working temperature: -20 °C ~ 70 °C
Storage temperature: -30 °C ~ 80 °C
Functions and Features
BYT12832 is a graphic dot matrix LCD modules. It mainly consists of row and column drivers drive components, can display 128 (columns) × 32 (OK) lattice. Complete graphical display can also display 8 × 2 pcs (16 × 16 dot matrix) characters. Seven control instruction, the CPU data bus interface uses 8 parallel input and output. Standard operating voltage of +5.0 V, when using VDD = +3.3 V, the need to factory settings; Meanwhile, according to customer needs, a variety of customized LCD modules.
Electrical parameters
Item Symbol Test Conditions Typical Units
Operating voltage VDD Ta = 25 °C 5.0 V
Operating Current IDD Ta = 25 °C, VDD = 5.0V 1.3 mA
