Plastic Knob Potentiometer
US$ 0.267 - 0.325
MOQ: 10000 Pieces
Key Specifications
Get Latest Price
Brand Name:
rocket
Model Number:
RV28P3
Type:
Other, Rotary Potentiometer, rotary carbon composition potentiometers
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Brand Name
rocket
Model Number
RV28P3
Type
Other, Rotary Potentiometer, rotary carbon composition potentiometers
Technology
Carbon Film
Resistance
100Ω-2MΩ
Resistance Tolerance
±20%
Rated Power
1-1.5w
Max. Operating Voltage
500V
Operating Temperature
60°C
Specifications
1) plastic knob potentiometer2)plastic shaft with sleeve,can be metal shaft
3)potentiometers since 1967 years
4)brand:rocket
Ningbo Huayu Electronics Co.,LTD
-
Rated power
A:1-1.5W
ing voltage
500V
Resistance range & tolerance
100Ω --2MΩ ±20%
Resistance tape
A. B . C.
End resistance
20 Ω max
Rotational noise
≤ 47mV
Shaft material
metal shaft,can be with plastic shaft
Rotation torque
2--20mN.m
Total mechanical travel
260°±10°
Mechanical life
10000cycles
All resistance below
-
-
B101-100Ω
B501--500Ω
B102--1k
B202--2k
B502--5k
B103--10k
B203--20k
B503--50k
B104--100k
B204--200k
B254--250k
B504--500k
B105--1M
-
Item No.: RV28P3 plastic knob potentiometer
