Home > Electrical & Electronics > Passive Components > Resistor & Potentiometer > Potentiometer Push Push Switch
US$ 0.2 - 2
MOQ: 10000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
rocket
Model Number:
WH160AK-4S
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
rocket
Model Number
WH160AK-4S
Type
Rotary Potentiometer
Technology
Carbon Film
Resistance
470Ω----2MΩ
Resistance Tolerance
±20%
Rated Power
A 0.125 W other 0.063W
Max. Operating Voltage
AC 150V
Operating Temperature
50 ℃
Specifications
1) potentiometer push push switch2)material :metal shaft
3)potentiometers since 1967 years
4)brand:rocket
5)Panel mounting
Ningbo Huayu Electronics Co.,LTD
Rated power | A:0.125W other 0.063w(50 ° ) |
ing voltage | AC 150V |
Resistance range & tolerance | 470Ω --2MΩ ±20% |
Resistance tape | A. B . C. |
End resistance | 20 Ω max |
Rotational noise | ≤ 47mV |
Shaft material | metal shaft,can be with plastic shaft |
Rotation torque | 4--80mN.m |
Total mechanical travel | 300°±5° |
Mechanical life | 10000cycles |
All resistance below
B101-100Ω
B501--500Ω
B102--1k
B202--2k
B502--5k
B103--10k
B203--20k
B503--50k
B104--100k
B204--200k
B254--250k
B504--500k
B105--1M
Item No.: WH160-AK-4S potentiometer push push switch
