sulfur grinder 100 mesh super fine machine
product show: military product
characteristics of sulfur impact mill:
Using fluid mechanics,Calculate the right flow field,The ideal pressure distribution,,Improve crushing efficiency greatly,Reduce energy consumption.
Can get much more fine particle size than the ordinary machine, Uniform particle size distribution, high precision Classification and no large particles, The product particle size can be adjustable arbitrarily at 100-500 mesh;
High efficiency low resistance cyclone is built, Dust filter bag adopted antistatic filter material, and it is the flame retardant materials.
Totally closed negative pressure operation, Pulse clear out automatically to make sure of the stability of the systems, Production environment is clean and no dust pollution.
The whole equipment is explosion-proof, Antistatic design/ antistatic finish, Equipped with pressure relief devices. Minimize the possibility of explosion.
high degree of automation, easy and simple operation.
technological process:
1, Material preparation
2 feed raw material
3 smash
4 Cyclone collect
5 Bag type collector
6 discharging collection
7 Nitrogen supplement and circulation
technical parameters:
model |
Max feed size |
discharging size |
Production capacity |
Installed power |
JSDL-CJM66 |
<2-5mm |
1-100um |
60-300kg/h |
10-18kw |
JSDL-CJM132 |
<2-5mm |
1-100um |
250-800kg/h |
13-15kw |
JSDL-CJM180 |
<2-5mm |
1-100um |
450-1000kg/h |
25-45kw |
JSDL-CJM330 |
<2-5mm |
1-100um |
850-2000kg/h |
35-86kw |
JSDL-CJM660 |
<2-5mm |
1-100um |
2100-4500kg/h |
60-182kw |
JSDL-CJM1500 |
<2-5mm |
1-100um |
3100-8000kg/h |
120-360kw |
model |
The largest feed particle size |
discharging granularity |
Production capacity |
Installed power |
JSDL-FJS180 |
<5mm |
200um95%of the sieve |
1.0-1.5t/h |
<45-54kw |
JSDL-FJS330 |
<5mm |
200um95%of the sieve |
1.74-2.3t/h |
<54-86kw |
JSDL-FJS660 |
<5mm |
200um95%of the sieve |
3.2-4/t/h |
<86-182kw |
JSDL-FJS660-1 |
<5mm |
200um95%of the sieve |
3.7-4.5t/h |
<182-204kw |
JSDL-FJS1500 |
<5mm |
200um95%of the sieve |
6.5-8.5t/h |
<204-372kw |
sulfur powder:
custom special sulfur imapct mill is accepted.
1. Quality -powerful military aerospace strength, the machine can operate 29 days continuously without rest.
2. Engineer-our engineer are both air power ultra expert with overall R&D strength and comprehensive competence, which
3. Service-we have professional sales team for pre-sales and after-sales services, also we will send engineer to your factory if you need.
We believe that our perfect products and excellent services will establish a win-win business relationship with you.
we Chengdu OUR Trading Co.,Ltd located in Chengdu where is a beautiful place, we factory is a military factory, so we offer high quality machine.
factory show:
workshop show:
tel: 028-69282335
mobile: 18782962236
Skype: wu.yao5
any question please feel free to contact me !
