Drum Dispenser - Power Lifing and Tilting Drum Stacker (Two-Stage)

Name: Drum Dispenser - Power Lifing and Tilting Drum Stacker (Two-Stage)
Brand: NU-LIFT
SKU: 130093833
Availability: InStock

US$ 1,800 - 2,500 MOQ: 2 Pieces

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

NU-LIFT

Model Number:

DA450A, DA450A-1, DA450B, DA450B-1

Nu-Lift Equipment Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name NU-LIFT

Model Number DA450A, DA450A-1, DA450B, DA450B-1

After-sales Service Provided Overseas third-party support available

Power lift and power drum tilt for ergonomic drum pouring.

Two-stage vertical-Lift drum pourers allow you to pour a drum up to 2450mm high

Model DA450A-1& DA450B-1: Scale-equipped drum stackers allow you to weigh your drum while you pour to dispense precise amounts as needed.

DA450A and DA450A-1

DA450B and DA450B-1

Model		DA450A	DA450A-1	DA450B	DA450B-1
Rated Capacity	KG	450	450	450	450
Max. Lifting Height	mm	2450	2450	2450	2450
Acceptable Drum Type		plastic, fiber	plastic, fiber	steel	steel
Powered Lifting	yes/no	yes
Drum Tilting (electric/manual)		electric
With Weighing Scale	yes/no	no	yes	no	yes
Lifting Speed	mm/s	120	120	120	120
Rotating Speed of Dumper		180°/30s	180°/30s	180°/30s	180°/30s
Load Rollers Size	mm	Ø80x60	Ø80x60	Ø80x60	Ø80x60
Steering Wheel Size	mm	Ø150x50	Ø150x50	Ø150x50	Ø150x50
Size Between Legs(Inner/Out)	mm	630/810
Leg Length	mm	740	740	740	740
Turning Radius	mm	1850	1850	1850	1850
Lifting Motor Power	KW	1.5	1.5	1.5	1.5
Battery	V/AH	12/120
Charger for Stacker	V	12
Charger for Weighing Scale	V	6
Overall Size(LxWxH)	mm	1500x950x2100	1500x950x2100	1500x950x2100	1500x950x2100
Net Weight	KG	330	335	336	340
