Help CenterRailway Fastener Induction Heating Machine for Forging
Related Products
-
Machine Tool Guide Rail Hardening Special EquipmentUS$ 886 - 9,800MOQ: 1 Set -
Railway Spring Fasteners Forging Induction Heating Machine Yongda WZP-450A/260KWUS$ 6,000 - 25,000MOQ: 1 Set
-
Induction Heating Hydraulic Cylinder Cladding MachineUS$ 890 - 9,800MOQ: 1 Set
-
Configuration of Concrete Pump Pipe Hardening EquipmentUS$ 860 - 9,800MOQ: 1 Set
-
Surface Hardening of Pipe for Concrete PumpUS$ 860 - 12,800MOQ: 1 Set
Specifications
high frequency induction heating device1.ISO9001
2. small size, light weight
3. high stability ,reliability
Railway fastener induction heating machine for forging
Features of railway fastener induction heating machine
1, my company transistor (IGBT) high frequency power-saving than vacuum tube up to 40-60%, saving 60%, external support facilities to reduce investment by 75%.
2, a unique cooling circulation system, ensure that the equipment 24 hours of continuous work.
3, small size, light weight, easy to move, no million-volt high-voltage danger, safe operation.
4, high reliability, easy to maintain and improve the over voltage, over current, overheating, lack of, water and other self-protection.
5, use large scale integrated circuit digital automatic control, with manual, automatic, semi-automatic, and the lack of heat insulation of cold sub-time control functions.
6, automatic frequency tracking, stepless power adjustment, easy to use, 10 minutes to learn to use.
7, the company has a complete sales service system and the treatment of professional engineers, to ensure that you have no worry about technology or service.
Equipment is consists of:
1. IF power cabinet 1 set
2. IF transformer 1 set
3. Induction heating loop 2 pieces
4. Automatic feeder machine 1 set
5. cooling unit 1 set
Technial parameters of induction heating machine
| Model | WZP-300 |
| Work power | 3 phase 380V+/-10%, 50-60HZ |
| Input voltage | 320V-420V can be changed, depend on your country's electric power |
| Input current | 6-300A |
| Input power | 3-160KW adjustable stepless |
| Oscillation frequency | 8-15KHZ also can be changed, depend on your work pieces size |
| Size of generator | 850*600*1330mm |
| Size of transformer | 780*540*520mm |
| Weight of generator | 147kgs |
| Weight of transformer | 108kgs |
| Cooling water pressure | 0.3 MPA |
Railway elastic bar fasteners heating equipment is used to heat forming diameter of 13-20mm railway elastic bar fasteners. The equipment has small size, quick installation, easy to learn operation.
Advantages : After using my compmany's railway elastic bar fastening heating equipment,elastic bar fasteners has sufficient strength, durable and a certain flexibility.
The equipment adopts IGBT as the main component, the power circuit in series is the basic characteristic oscillation control circuit at a frequency automatic tracking, multi-phase-locked loop and closed-loop control.
Induction heating railway elastic bar process:
Fasteners three times forge press hot forming machine
Railway elastic bar fasteners one time hot forming machine
My company can customize elastic bar fasteners one time forming machine, three times forming machine, and full sets mold.
Our workshop for debugging induction heating machine: only good machine will be sent to our customers
Product quality certificatioins: ISO9001-2000
Shenqiu Yongda High Frequency Equipment Co., Ltd. was founded in 1996, which belongs to high-tech enterprise in Henan Province,China. We are located in Shenqiu County, Zhoukou City. We professionally dedicated to R&D,production of HF,SSF,MF induction heating equipment,adhering to the spirit of innovation, mean while strengthening cooperation with domestic well-known universities and research institutions. We are the leader of domestic induction heating field, and got the ISO9001:2000 international quality management system certification in August, 2004. Up to now, we has 83 office in domestic ,products hot sale , and also exported to Europe,America,and Southeast Asia etc. other regions.
Packing railway fastener induction heating machine:
Two wooden cases (plywood) Inside,will be filled with plastic foam,for waterproof and shockproof.
Accessories: induction coils,foot switch and installing and operating instructions
Shipping: by sea LCL(less than container load) or by air.
Pre-sale service:
We will recommend the most applicable equipment for customers according to your work piece processing demands.
In-sale service:
(1) We will strictly produce the equipment according to relevant technical standards.
(2) We will take run test according to relevant equipment test run regulations.
(3) We will strictly inspect the equipment before delivery,only good machine will be sent to customers.
(4) We will send goods as scheduled in the contract.
After-sale service:
(1) We will freely guide installation, commissioning and test run,by sending intall drawings, sometimes calling or send email.
(2) We will execute one-year guarantee period (ex. not include normal wear, damages of wearing parts and parts damages caused by improper operation).
(3) Once there is a trouble during quality guarantee period, our company promises that we will promptly appoint engineer and sales to help, make our efforts to remove troubles and guarantee the normal operation of customers.
(4) We will freely replace all equipment parts during guarantee period. After-sale products archives and life-long repair solve the potential problems of customers.
(5) Provide long-terms technical support. Also for different work pieces , give instructions and help about how to produce inductors.
(6) According to customer’s need, can arrange engineer to install ,test machine and training operators.
(7) After guarantee period, customer can buy machine parts from us with very low cost.
| What’s your MOQ? | Any quantity of machine will be accepted. MOQ:1 Set |
| Which place your factory is located? | We are located in Shenqiu County, Zhoukou city, Henan Province ,China |
| How far from Beijing? I think it is more closer to Shanghai | Our factory is near both and Shanghai. We have office in Zhengzhou, we can pick up you at Zhengzhou CGO airport,and then to our factory via expressway about two hours. |
| We need to see some more videos for production line and also pictures of your factory, water drawing and panel drawing |
Well, we have many videos show our customer’s machine working scene(Various of applications: forging,hardening, brazing, shrink fitting, melting and hot coating etc. According to your work piece processing requirements,) send you the corresponding video link or send by email. 2. Yes, we can provide you factory pictures and machine water connection and control panel details. |
| Do you have quality certifications? | Yes, we got the ISO9001:2000 International quality management system certification in August,2001, |
| How do you packing the machines? |
Standard export wooden cases(plywood) Usually every set machine will be used two wooden cases: one for packing induction heating generator, one for packing transformer. Inside will be filled with plastic foam for waterproof and shockproof |
| More questions….? | Updating… |
Thanks for your reading ! Welcome to contact us !
