Super audio small induction melting furnace
Shenqiu Yongda High Frequency Equipment Co., Ltd. was founded in 1996, which belongs to high-tech enterprise in Henan Province,China. We are located in Shenqiu County, Zhoukou City. We professionally dedicated to R&D,production of HF,SSF,MF induction heating equipment,induction melting furnace,adhering to the spirit of innovation, mean while strengthening cooperation with domestic well-known universities and research institutions. We are the leader of domestic induction heating field, and got the ISO9001:2000 international quality management system certification in August, 2004. Up to now, we has 83 office in domestic ,products hot sale , and also exported to Europe,America,and Southeast Asia etc. other regions.
Our factory
Technial parameters of IGBT induction melting furance
Model |
Steel and stainless steel |
Gold, silver, copper |
Aluminum |
WZP-15 |
----- |
10kg |
3kg |
WZP-25 |
5kg |
20kg |
6kg |
WZP-35 |
10kg |
30kg |
10kg |
WZP-45 |
18kg |
50kg |
20kg |
WZP-70 |
25kg |
100kg |
30kg |
WZP-90 |
40kg |
120kg |
40kg |
WZP-110 |
50kg |
150kg |
50kg |
WZP-160 |
100kg |
250kg |
100kg |
WZP-300 |
200kg |
500kg |
200kg |
Performances and features
1.Using a zero-voltage scanning soft-start mode, in any case may at any time to start or stop, will not have impact on power supply.
2. Fast smelting with low production cost; low-pollution and environment-friendly ;
3. A direct effect from the cold furnace melting. Dissolved material will be fully dumped clean. Molten material easy to replace.
4. Power adjustment flexibility. Be able to continuously smooth adjustment. Temperature uniformity can be easily controlled. Oxidation burning less. Metal components evenly.
5. Furnace shell using cast aluminum or steel structure, small footprint; furnace flip dump convenience, according to the need to use electric, manual, hydraulic tilting furnace and other means.
6. Designed to automatically adjust angle of inverter circuit that can automatically adjust the load impedance match, without adjustment of capacitance compensation and always run the equipment in good working condition; power supply system diagnostic error function, easy maintenance.
Applications of induction melting furnace
smelting for iron , steel , cooper , aluminum
smelting for presious metals , such as gold , sliver ,
smelting for ferrous and non ferrous metals
smelting for alloys
smelting for metal rods
other smelting work for metal product
Mechanical overturned type induction melting furnace
1. Induction heating power supply
2. Inducton melting furnace or simple induction coils
More application
Packing for induction melting furnace:
Wooden cases (plywood) Inside,will be filled with plastic foam,for waterproof and shockproof.
Accessories: induction coils,foot switch and installing and operating instructions
Shipping: by sea LCL(less than container load) or by air.
1. Reply your inquiry within 24 working hours
2. Experienced engineer instruct and sales communicate with you in fluent English.
3. According to work pieces specifications, heating requirements, propose best solutions,also reference your ideas.
4. Machine details and working video link for your reference
5. Competitive price ,compare with the same industry
6. Production: strict quality standard, to produce machine and induction coils.
7. Debugging machine and only good machine will be sent.
8. Tracking goods shipping and provide bill of lading,invoice,packing list and other documents what you need
9. Provide install and technology instruction by sending drawings, email, or telephone,video.
10.If you need, will arrange one engineer to your place,instruct install machine and training operators.
11.Provide long-terms technical support
