Power saver high frequency induction brazing machine
Features of power saver induction brazing machine
First, the high-frequency welding machine welding tool can be used in alloys welding,For example: alloy turning, milling, planer, saw, reamer, boring and so on.
Advantages for welding alloy cutting tools:
1, induction heating speed, high efficiency
2, simply put pieces of copper or silver solder between the head and the substrate properly
3, energy saving and low cost
4, the oxidation is in small area
5, the appearance is exquisite after welding
6, uniform heating, hence there is no shortage of spot welding and leakage
Second, the advantages of high frequency welding machine for brazing metal parts:
1, induction heating speed, high efficiency
2, low-cost energy saving
3, one can weld multiple parts, so that the welding efficiency is improved
4, the oxidation is in small size
5, uniform heating,have no lack of welding and leak-free solder joints
6, the workpiece after welding appearance is fine, solid
Third, the high-frequency welding machine for welding marble saw blades, wood saw blade brazing, its advantages are:
1, efficient, rapid welding gear, each tooth 1-5 seconds
2, reproducible and have good reproducibility for each tooth
3, heating quickly and evenly, can effectively prevent local overheating caused by jagged and brittle fracture, can prevent the teeth out of welding negative phenomena which caused by lack of penetration etc
4, can weld high-performance, high hardness, serrated blade, the blade can not be welded by resistance welding
5, less electricity consumption
Technical specifications of power saver induction brazing machine
Model |
Input voltage |
Input current |
Oscillation frequency |
Cooling water pressure |
WZP-40 |
320-420V |
2-40A |
15-30KHZ |
0.1MPA |
WZP-60 |
320-420V |
3-60A |
15-30KHZ |
0.2MPA |
WZP-90 |
320-420V |
4-90A |
15-30KHZ |
0.3MPA |
WZP-120 |
320-420V |
6-120A |
15-30KHZ |
0.3MPA |
WZP-160 |
320-420V |
6-160A |
15-30KHZ |
0.3MPA |
WZP-200 |
320-420V |
6-200A |
15-30KHZ |
0.3MPA |
WZP-300 |
320-420V |
6-300A |
15-30KHZ |
0.3MPA |
WZP-400 |
320-420V |
6-400A |
8-15KHZ |
0.3MPA |
WZP-500 |
320-420V |
6-500A |
8-15KHZ |
0.3MPA |
Applications of power saver induction brazing machine
1. metal tube welding:
such as copper tube, steel tube, and aluminum tube’s butt welding, plug welding and
welding sets.
2. alloy cutter welding:
such as alloy turning, milling cutter, planer, saw blades, reamer, boring knife.
3. carbide saw blade welding:
diamond saw blade welding, marble saw blade welding,woodworking saw blade welding,
cut grass piece of welding, cut aluminum welding,
4. metal welding:
such as: towel rack, soap nets, towel holder, auto-accessories,
moto accessories, metal terminals, hardware pieces, electric heating tube parts and fasteners.
Product quality certification:ISO9001:2000
Packing for power saver induction brazing machine
Two wooden cases (plywood) Inside,will be filled with plastic foam,for waterproof and shockproof.
Accessories: induction coils,foot switch and installing and operating instructions
Shipping: by sea LCL(less than container load) or by air.
1. Reply your inquiry within 24 working hours
2. Experienced engineer instruct and sales communicate with you in fluent English.
3. According to work pieces specifications, heating requirements, propose best solutions,also reference your ideas.
4. Machine details and working video link for your reference
5. Competitive price ,compare with the same industry
6. Production: strict quality standard, to produce machine and induction coils.
7. Debugging machine and only good machine will be sent.
8. Tracking goods shipping and provide bill of lading,invoice,packing list and other documents what you need
9. Provide install and technology instruction by sending drawings, email, or telephone,video.
10.If you need, will arrange one engineer to your place,instruct install machine and training operators.
11.Excess warranty period(12 months warranty), you can buy the spare parts from us with special discount price.
12.Provide long-terms technical support
Quality assured ! Low cost ! Considerate service ! Shenqiu Yongda welcome you ! Thanks for your reading ! Welcome to contact us !
