45kw Annealing furnace for steel bar
Technical parameters of 45KW annealing furnace for steel bar
| Model | Work power | Output power | Oscillation frequency | Output current | Cooling water pressure | Size | Weight |
| WZP-90 | three phase 380V+/-10% 50-60HZ | 3-45KW | 15-30KHZ | 3-90A | 0.1MPA |
generator 665×400×730mm transformer 660×490×435mm |
62kgs; 47kgs |
Annealing furnace for steel bar
Features of annealing furnace
Heating fast: this is the heating rate of less than 1 second (speed adjustable speed control)
Heating wide: wide range of metal parts can be heated (according to the different shape of the workpiece replacement of removable induction loop)
Easy installation: connect the power, induction loop and out of the water can be used; small size, light weight, easy to use
Simple operation: a few minutes to learn
Start fast: you can start with water after the heating power
Low power consumption: high-frequency device than the old-fashioned tube about 70% energy saving, the smaller the power consumption of the smaller parts
Good effect: the heating is very uniform (also by regulating the induction coil density, so that all parts of the workpiece to obtain their desired temperature), heating up fast, less oxide layer after annealing without waste
Adjustable power: The Promise adjust the output power
Protection all: with over voltage, over current, overheating, lack of water and other alarm indicator, and automatic control and protection
Applications of annealing furnace
(1) Stainless steel: stainless steel cups, stainless steel sink, stainless steel boxes, pans, pots, buckets, cutlery, forks, spoons,
(2), other types:
Metal strap flange, exhaust pipe flange, chain annealing, punching, the fans rivet heating, mine screen annealing.
Pumping gas pipe
More different power of annealing furnaces
Model |
Input voltage |
Input current |
Oscillation frequency |
Cooling water pressure |
WZP-40 |
320-420V |
2-40A |
15-30KHZ |
0.1MPA |
WZP-60 |
320-420V |
3-60A |
15-30KHZ |
0.2MPA |
WZP-90 |
320-420V |
4-90A |
15-30KHZ |
0.3MPA |
WZP-120 |
320-420V |
6-120A |
15-30KHZ |
0.3MPA |
WZP-160 |
320-420V |
6-160A |
15-30KHZ |
0.3MPA |
WZP-200 |
320-420V |
6-200A |
15-30KHZ |
0.3MPA |
WZP-300 |
320-420V |
6-300A |
15-30KHZ |
0.3MPA |
WZP-400 |
320-420V |
6-400A |
8-15KHZ |
0.3MPA |
WZP-500 |
320-420V |
6-500A |
8-15KHZ |
0.3MPA |
Pictures of annealing furnace
