plastic pipe cutter (hydraulic and planetary)

Specifications

plastic pipe cutter (hydraulic and planetary)
1.high efficiency-cutting
2.adjustable cutting depth and speed
3.safe-operat

 plastic pipe cutter (hydraulic and planetary)

1.high efficiency-cutting capacity
2.adjustable cutting depth and speed
3.safe-operation

Feature:

1)It is mainly used in cutting plastic pipes like PVC/UPVC pipes, HDPE/PP/PPR pipes

2)The cutting of the products do not produce chips, and cut sections smoothing products,thus saving products, raw materials, but also conducive to products with the corresponding pipes connector.

2)The cutting of the products at the line can be carried out simulaneously at any time,you can cut  at any time of sampling a section of pipe when not on the production line

3)Cutting the process smooth.

4)High automation, high cutting quantity and appearance is beautiful



Main technical parameter:

Model	GR250	GR400	GR630
Max. cutting diameter (mm)	250	400	630
Saw diameter (mm)	130	150	220
Rotating motor power (kw)	0.75	1.1	1.5
Cutting motor power (kw)	2.2	2.2	3
Advancement motor power (kw)	0.25	0.25	0.55
Cutting pipe wall thickness (mm)	within20	within20	within20
Dimension (mm)	2700*1000*1500	2700*1300*1700	2700*1500*2000
