Specifications
(1)PE Plastic Pipe production line(2)PE pipe production line
(3)Plastic pipe production line
PE Plastic Pipe production Line:
1) Application: this PE Plastic pipe production line is suitable for pipe line which uses PE, PPR, PP,
PPB, PPC, and ABS resins as its raw material
2) Characteristics:
a) Man-machine operation interface, high automation level
b) The adoption of professional screw ensures good plastification
c) Adopts compound screw type head to clear memory function effectively
d) Vacuum forming, constant temperature control to remove stress of pipe
material
e) Adopts common extruding head and adds marking color line for pipe material
2) Technology parameter of the PE Plastic pipe production line:
a) Models: SJPG-65, SJPG-90, SJPG-120
b) Main motor power (kW): 30 - 37, 55 - 75, 90
c) Cylinder heating power (kW): 23, 34, 48
d) Length-diameter ratio: 30:1, 30:1, 30:1
e) Vacuum pump power (kW): 5.5, 7.5, 7.5
f) Water pump power (kW): 4, 4, 4
7) Drawing motor power (kW): 3, 4, 5.5
8) Cutting power (kW): 2.2, 2.2, 3
Standard PE Plastic pipe production line model:
| Unit Model | SJPG-65 | SJPG-90 | SJPG-120 |
|
Main motor power(kw) |
30-37 | 55-75 | 90 |
|
Cylinder heating power(kw) |
23 | 34 | 48 |
|
Length-diameter ratio |
30: 1 | 30: 1 | 30: 1 |
|
Production capacity(Kg/h) |
80-100 | 120-150 | 200-220 |
|
Vacuum pump power(kw) |
5.5 | 7.5 | 7.5 |
|
Water pump power(kw) |
4 | 4 | 4 |
|
Mobile motor power(kw) |
0.75 | 0.75 | 1.1 |
|
Drawing motor power(kw) |
3 | 4 | 5.5 |
|
Cutting motor power(kw) |
2.2 | 2.2 | 3 |
|
Power(kw) |
72 | 110 | 160 |
|
Equipment arrangement length(mm) |
30 | 36 | 42 |
