"TEDE Telephone Modular Plug,rj11 Connector,cat3 6p4c

Specifications

Modular plug 8P8C RJ45,RJ11 RJ12 :

Specifications

The Plug offer support for phone or voice applications in home or office abling systems

Current Rating:1.5 AMPS at 25'C

Voltage Rating:125 V AC

Insulation Resistance:1000 MΩ Min. at 500V DC EIA-364-21C

Withstand Voltage:1000 V AC RMS OR 1500 V DC at 0.5mA 50 Hz/60Hz Minute EIA-364-20B

Contact Resistance:40 mΩ Max. EIA-364-23B Mechanical

Retention Strength:57.83N Min.EIA-364-98

Durability:1000 Mating Cycles Min. Environmental

Operation Temperature:-20'C~+70'C

Storage Temperature:-10'C~+40'C Relative Humidity<80% Material

Housing:PC

Flammability Class:UL94V-0/V-2

Terminal:Thickness 0.35mm Phosphor Bronze Selectrive Gold Plating Over Nickel

Gold Plating: G/F inch,3u Inch,6u inch,15u inch,30u inch,50u inch

Package

100pcs/box

Shipping

Our services

Tede Series Networking products

we could offer you one-stop purchase services.

Our strength

Why choose us ?

We specialize in manufacturing all types of networking products such as cables,patch panels,jacks,plugs,face plates,cabinets,fiber cables,patch cords,switch,routers and wireless equipment. Our own brand is"TEDE".We also act as agents of many famous companies.We have 8 automatic production lines operated by skillful workers.All of our products are produced strictly according to the ISO9001 standards,we offer fine after-sales services. If there is any question you want to know,pls contact us at any time.

Orders

Our products are popular with North America,South America,Eastern Europe,Western Europe,Central America,Northern America,Northern Europe,the Middle East,Africa.And they achieved good reputation at the same time. We can also offer OEM and ODM service according to customer's requirements.Always welcome your order!

Delivery

In general,we deliver goods within 7-10 days after we received your payment.Bye the way,we could provide competitive shipping terms service for u,by sea,by air or by express delivery.Of course, you can appoint another.

Any question, please not hesitate to contace us!
