Help CenterSimple Cutting Equipment
Related Products
We are professional manufacturer in China for pipe production line and plastic auxiliary machine.
We have rich experience in manufacturing such machines. If you are going to purchase such machinery, we hope we can be of help.
Precision hydraulic4-colum plane cutting machine
Model |
XK3-300 |
XK3-350 |
XK3-500 |
XK3-600 |
XK3-800 |
XCLP3-1000 |
Maximum cutting force |
300KN |
350KN |
500KN |
600KN |
800KN |
1000KN |
Distance between the upper platen and the working table surface |
50-160mm |
50-160mm |
55-195mm |
50-200mm |
50-200mm |
50-200mm |
Area of the working table |
550*1600mm 550*1220mm |
610*1600mm 610*1220mm |
750*1600mm 750*1220mm |
900*16oomm 900*1220mm |
750*1600mm 750*1220mm |
900*1600mm 900*1220mm |
Motor power |
1.5KW |
2.2KW |
3KW |
4KW |
5.5KW |
5.5KW |
Hydraulic oil quantity |
150L |
180L |
200L |
220L |
320L |
33OL |
Machine weight |
2500kg |
3100kg |
3500kg |
4100kg |
45ookg |
5100kg |
A, Oil is supplied to all sliding parts of this machine by the hydraulic system for lubrication, reducing wear and prolonging the service life of the machine.
B, The upper platen may automatically cut slowly as it presses down rapidly to the knife mold for cutting so that there will be no dimension errors between the upper and lower layers of the cutting materials.
C, Structural changes during designing of this machine remove the need for the users to worry about possible oil leakage of the machine.
D, External motor and oil pump enable good ventilating and cooling conditions, safely operating and prolonged service life.
E, Setting of the knife mold is rapid, accurate and easy-to-learn.
F, Small motor power results in low power consumption.
Welcome to visit our company
