Specifications
linear amplifier(1) 8 ohms Stereo Power:2X750W+1500W
(2) 4 ohms Stereo Power:2X1150W+2300W
(3) 3-channel
(4) CE
LINEAR AMPLIFIER SPECIFICATIONS
|
Model
|
G75.15 |
| Features | 3-channel. Type H Amplificatory Circuit, double-face Circuit Board, SMT process. Exellent self-protection |
| Power | 8 ohms Stereo Power: 2X750W+1500W |
| Distortion, SMPTE | <0.05% |
| Hum&Noise | -101dB |
| Damping Factor | > 400 @ 8Ω |
| Input Sensitivity | 1.22V |
| Frequency Response | 20Hz-20kHz,+0/-1 dB |
| Input Impedance | 10kΩ Unbalanced,20kΩ Balanced Controls |
| Inputs | XLR |
| Outputs | binding posts and Speakon outputs |
| Cooling | continuously variable speed fan,rear to front airflow |
| Amplifier Protection | short circuit,open circuit, thermal,ultrasonic, |
| Power Requirement | 220 Volts AC (±10%) 50-60Hz |
Dimension & Weight:
Amp Dimensions(H*W*L): 132mmX483mmX490mm
Carton Dimension(H*W*L): 195mmX600mmX640mm
Net Weight: 32.5kg
Gross Weight: 36.9kg
More pictures:
linear amplifier front view:
linear amplifier top view:
linear amplifier rear view:
