SMZG 100C Toothpaste Plastic Tube Body Making Machine Directly From the Factory

Specifications

                                              SMZG 100C toothpaste plastic tube body making machine direct from the factory

 I. Brief Introduction

Model SMZG-100C Tube Body Maker Machine. It is new generation tube processing equipment that is developed successfully.
It is controlled by PLC contacting and pressing man-machine dialogue screen function firm operation and adjustment easy. It specializes in welding the side crack of compound soft tube cracks keep firmly and smoothly; it can cover the outer aluminum foil, while welding aluminum-plastic-compound soft tube. It can keep the filling products in good quality for a long time. It is widely used in the producing of products, packing soft tube such as creams, lotions including toothpaste, food, medicine,  cosmetics and etc.

II. Main technique parameter

Tube Length:	65-200mm	Tube Diameter:	12.7-50mm
Power Supply:	220VAC/50 Hz	Power of the Machine:	10KW
Cooling water requirements :	water pressure0.2MPa;	Flow capacity	3 to 5 L /minute, soft water
Air pressure requirement	0.5-0.7MPa (remove water, oil)	Shape size:	3300X1900X1200mm
		Machine weight:	1800kg
