Turnkey EPC contractor for the HFO power plant with finance solution. TOP 10 power project contractor in China.We are the Henan branch of CMEC, CMEC is a large global conglomerate with the contracting of the international engineering projects and the export of complete plants as its core business and its main business includes the foreign trade business , R & D work and design as well the international service trade.
CMEC ranked 6th among the top fifty enterprises listed by Ministry of Commerce in China in terms of the business turnover completed in foreign contracting projects of China in 2007; the 9th among the top fifth enterprises in terms of the amount of newly signed contracts for foreign contracting projects of China; CMEC has been listed among the largest 225 contractors in the world by a famous magazine in the United Stated, Engineering News-Record for several consecutive years, and ranked the 64th in 2003.
We could supply Turnkey Service for your power plant construction From the Finance to the EPC.
Our CMECL32/40 HFO generator is based on MAN HFO engine, the technical data is as following:
| 50Hz | 60Hz | ||
Model | Engine power | Generator power | Engine power | Generator power |
CMEC6L32/40 | 3000KW | 2895KW | 3000KW | 2895KW |
CMEC7L32/40 | 3500KW | 3380KW | 3500KW | 3380KW |
CMEC8L32/40 | 4000KW | 3860KW | 4000KW | 3860KW |
CMEC9L32/40 | 4500KW | 4340KW | 4500KW | 4340KW |
Bore 320mm, Stroke 400mm | ||||
Speed(r/min) | 750 | 720 | ||
Mep.(Bar) | 24.9 | 25.9 | ||
Piston Speed(m/s) | 10.0 | 9.6 | ||
Consumption | ||||
Power | 100% | 100% | ||
Heat rate | 7643KJ/KWhm;7879KJ/KWhe | |||
Specific lube oil consumption | 6Cyl.:1.8Kg/h; 7Cyl.:2.1Kg/h; 8Cyl.:2.4Kg/h; 9Cyl.:2.7Kg/h; | |||
Model | ATS250 | ATS400 | ATS630 | ATS800 | ATS1000 | ATS1250 | ATS1600 | ATS2000 | ATS2500 | ATS3150 | ATS4000 | ATS6300 |
Capacity | 250A | 400A | 630A | 800A | 1000A | 1250A | 1600A | 2000A | 2500A | 3150A | 4000A | 6300A |
Standard Type | VS | VS | VS | VS | VE | VE | VE | VE | VE | VE | VE | VE |
CMEC diesel/natural gas dual-fuel engine & gen | ||||||||
Engine Model | Model | Cylinder number | Bore stroke | Starting method | Comprehensive substitution rate | Engine Rated Power (KW) | Lube oil consumption (g/kw.h) | Diesel/natural gas dual-fuel gen rated power (KW) |
CMECV8 | Four stroke, water cooled, turbo charged inter cooled | V8 | 170/195 | natural gas & diesel mixed | ≥70 | 829 | ≤1g/kw.h | 750 |
CMECV12 | V12 | 160/240 | 1200 | 1000 | ||||
CMECV16 | V16 | 1680 | 1500 | |||||
CMEC16/24 | L5 | natural gas & heavy oil mixed | 430 | ≤0.7g/kw.h | 400 | |||
L6 | 500 | 450 | ||||||
L7 | 600 | 500 | ||||||
L8 | 660 | 600 | ||||||
L9 | 770 | 700 | ||||||
CMEC21/31 | L5 | 210/310 | 900 | ≤0.8g/kw.h | 800 | |||
L6 | 1250 | 1000 | ||||||
L7 | 1450 | 1200 | ||||||
L8 | 1650 | 1500 | ||||||
L9 | 1850 | 1700 | ||||||
