Home > Products > Residual Current Circuit Breaker > BDL17G-63 ORANGE 2P RESIDUAL CURRENT CIRCUIT BREAKER
BDL17G-63 ORANGE 2P RESIDUAL CURRENT CIRCUIT BREAKER
USD $2.35 - $3.88
/ Piece
10 Pieces(Min.Order)
- 200000 Piece / Pieces per Month
- Ningbo Wenzhou
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | BODUN | Model Number: | BDL17G-63 |
| Type: | Earth Leakage | Poles Number: | 2 |
Product Description
Specifications
1,Orange Series.2,IEC1008
3,16,25,40,63A
4,10ka
BDL17G-100 RCCB (Residual Current Circuit Breaker)
| Construction and Feature |
| Provides protection against earth fault/leakage current and function of isolation. High short-circuit current withstand capacity Applicable to terminal and pin/fork type busbar connection Equipped with finger protected connection terminals Bakelite parts endures abnormal heating and strong impact Automatically disconnect the circuit when earth fault/leakage current occurs and exceeds the rated sensitivity. Independent of power supply and line voltage, and free from external interference, voltage fluctuation. |
| Technical Data |
| Model:electro-magnetic type,electronic type Residual current characteristics:A,AC Pole NO.:2,4 Rated making and breaking capacity:630A Rated current(A):16,25,40,63 Rated voltage:240/415V AC Rated frequency:50/60Hz Rated residual operating current In(A):0.03,0.1,0.3,0.5 Rated residual non operating current Ino:0.5In Rated conditional short-circuit current Inc:10kA Rated conditional residual short-circuit Current Ic:10kA Tripping duration:instantaneous tripping ≤0.1s Residual tripping current range:0.5In~In Terminal Connection Height: 21mm Electro-mechanical endurance: 4000 cycles Connection capacity: Rigid conductor 25mm2 Connection terminal: Screw terminal Pillar terminal with clamp Fastening torque:2.0Nm Installation: On symmetrical DIN rail 35mm Panel mounting |
