Help CenterBDL16-100 PG RCCB
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
BODUN
Model Number:
BDL16-100
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Wenzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
BODUN
Model Number
BDL16-100
Type
Residual Current
Poles Number
2
Specifications
1,PG Model RCCB.2,Pole:2,4P
3,25-125A.
4,Conform to IEC standard.
BDL16-100 Residual Current Circuit Breaker
| Technical Data |
| Model:electro-magnetic type,electronic type Residual current characteristics:A,AC Pole NO.:2,4 Rated making and breaking capacity:630A Rated current(A):25,40,63,80,100,125 Rated voltage:250/440V AC Rated frequency:50/60Hz Rated residual operating current In(A):0.03,0.1,0.3,0.5 Rated residual non operating current Ino:0.5In Rated conditional short-circuit current Inc:6kA Rated conditional residual short-circuit Current Ic:6kA Tripping duration:instantaneous tripping ≤0.1s Residual tripping current range:0.5In~In Electro-mechanical endurance: 4000 cycles Connection capacity: Rigid conductor 35mm2 Installation: Panel Mounting |
