QC12K series hydraulic CNC pendulum plate shearing machine

FOB Price

USD $9,000 - $20,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Shanghai port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Place of Origin:	Anhui, China	Brand Name:	Hudong
Model Number:	QC12E18-6*4000	Certification:	ISO9001:2000	Warranty:	12 months after saling
Voltage:	optional

Product Description

Description:

1.stepless control for the stroke,the gap between up blade

and down blade is manually adjusted by handle for high uniformity.

tection fence and the electric interlock to ensure the operation safety.

3.the close loop control system that consists of CNC system and position

coder features fast response speed,high precision and exceptional stablity

and can ensure the accuracy of displacement of backgauge.

4.E18 CNC system has the accessory functions of compensation

and automatic check.

Technical data:

Model	Shearing size (T×W)(mm)	Shearing angle	Strokes (min^-1)	Adjusting scope of back stop (mm)	Motor power (KW)	Weight (Kg)	Overall dimension (L×W×H)(mm)
QC12Y4×2500	4×2500	1°30’	≥16	20-600	5.5	3200	3040×1580×1600
QC12Y4×3200	4×3200	1°30’	≥12	20-600	7.5	4600	3840×1610×1650
QC12Y4×4000	4×4000	1°30’	≥10	20-600	7.5	5900	4640×1880×1700
QC12Y6×2500	6×2500	1°30’	≥16	20-600	7.5	4800	3040×1610×1650
QC12Y6×3200	6×3200	1°30’	≥12	20-600	7.5	5600	3840×1610×1650
QC12Y6×4000	6×4000	1°30’	≥10	20-600	7.5	7150	4640×1880×1700
QC12Y6×5000	6×5000	1°30’	≥8	20-600	11	11000	5786×2200×2160
QC12Y6×6000	6×6000	1°30’	≥7	20-600	15	16000	6900×2570×2280
QC12Y8×2500	8×2500	1°30’	≥12	20-600	17.5	5500	3040×1610×1650
QC12Y8×3200	8×3200	1°30’	≥10	20-600	17.5	6700	3840×1610×1650
QC12Y8×4000	8×4000	1°30’	≥8	20-600	11	8300	4680×1880×1700
QC12Y8×5000	8×5000	1°30’	≥7	20-600	15	14000	5786×2200×2160
QC12Y8×6000	8×6000	1°30’	≥5	20-600	18.5	19000	6900×2570×2280
QC12Y10×2500	10×2500	2°	≥10	20-600	11	7200	3350×2050×1950
QC12Y10×3200	10×3200	2°	≥9	20-600	11	8300	4050×2050×1950
QC12Y10×4000	10×4000	2°	≥8	20-600	15	10700	4800×2200×2100
QC12Y12×2500	12×2500	2°	≥10	20-800	15	8600	3225×2127×2235
QC12Y12×3200	12×3200	2°	≥9	20-800	18.5	9800	4820×2350×2235
QC12Y12×4000	12×4000	2°	≥8	20-800	18.5	11200	4820×2350×2300
QC12Y16×2500	16×2500	2°	≥8	25-800	18.5	9860	3245×2127×2235
QC12Y16×3200	16×3200	2°	≥7	25-800	18.5	10800	3945×2127×2235
QC12Y16×4000	16×4000	2°	≥5	25-800	22	12600	4850×2350×2300
QC12Y20×2500	20×2500	2°30’	≥6	30-800	22	15000	3440×2088×2570
QC12Y20×3200	20×3200	2°30’	≥5	30-800	37	18000	4150×2088×2570
QC12Y20×4000	20×4000	2°30’	≥5	30-800	37	23000	4920×2400×2730
QC12Y25×2500	25×2500	3°	≥5	30-800	37	17000	3500×2400×2500
QC12Y25×3200	25×3200	3°	≥4	30-800	37	20000	4200×2400×2500
QC12Y25×4000	25×4000	3°	≥4	30-800	37	26000	4950×2500×2600
