QC12Y Series Hydraulic Pendulum Plate Shears
1. This machine adopts hydraulically transmission. The machine frame adopts steel plate welded structure with enough strength and rigidity.
2. Nitrogen return makes it convenient to operate, reliable in performance and beautiful in appearance.
3. Indicator adjustment for the gap of blades is convenient and fast.
4. This machine uses protection fence for safety operation.
5.Digital display unit is equipped for displaying the size of back stop and shearing information
Technical Data
NO |
Name |
Data |
Unit |
1 |
Shearing thickness |
8 |
mm |
2 |
Shearing length |
2500 |
mm |
3 |
Shear angle |
1°30 |
|
4 |
The times of stroke |
≥12 |
Min |
5 |
The range of back gauge |
20-600 |
mm |
6 |
Weight |
5500 |
kg |
7 |
Overall dimension |
3040×1610×1650 |
mm |
8 |
Main motor |
7.5 |
kw |
9 |
Axial piston pump |
25MCY14-1B |
|
