hydraulic CNC guillotine shearing machine (4mmx3200mm)
Technical characteristics
1. The frame is steel welded structure, have sufficient strength and rigidity, eliminate internal stress and high frequency vibration, to ensure the overall accuracy of the fuselage. Has a good rigidity, two cylinders fixed on the left and right columns (wallboard).
2. Blades has four sides, every side can be use.
3. E20 NC system control , it digital display , also can simple locate and control back gauge.
4.Hydraulic guillotine shearing machine is second generation shearing machine.
we can adjust shear angle and blade gap. hydraulic swing beam shearing machine just adjust blade gap.
Technical data:
Max. thickness of plate |
4mm |
Max. width of plate |
3,200mm |
Workbench thickness |
30mm |
Wallboard thickness |
25mm |
Anti-strength of plate |
450N/mm2 |
Shear angle |
0.5°-1.5° |
Back gauge range |
550mm |
Stroke times |
15-26times/min |
Throat depth |
130mm |
Blade length |
3,300mm |
Main motor |
5.5KW |
Oil pump |
10MCY14-1B |
Dimension(LxWxH) |
3600×1500×1800(mm) |
Machine weight |
5.2T |
