Pit Bright Annealing Furnace
Usage:The iron parts bright treatment annealing in vacuum or in protect atmosphere.
Structure Description:The pit bright annealing furnace formed with:door,iron sheel,lining,electric control system,etc.
Features:
1:The furnace sheel made by high quality steel,the lining is stacked by refractory material,it has a high quality of insulation and efficiency.
2.The sealing system use the composite structure,graphite asbestos article used inside and silicone outside.
3.The electric control system including digital instrument and PID control have high accuracy.
| Furnace type |
Power (KW) |
Temperature (°c) |
Distrct heating (°c) |
Dimension (mm) |
Price (U.S.Dollar) |
| RJZ-35-9 | 35 | 850 | 1 | Φ400×600 | 8,080.00 |
| RJZ-45-9 | 45 | 850 | 1 | Φ600×800 | 9,000.00 |
| RJZ-60-9 | 60 | 850 | 1 | Φ700×900 | 11,200.00 |
| RJZ-70-9 | 70 | 850 | 1 | Φ700×1200 | 12,000.00 |
| RJZ-80-9 | 80 | 850 | 1 | Φ800×1000 | 12,300.00 |
| RJZ-90-9 | 90 | 850 | 1 | Φ800×1200 | 12,500.00 |
| RJZ-95-9 | 95 | 850 | 1 | Φ900×1200 | 12,700.00 |
| RJZ-100-9 | 100 | 850 | 2 | Φ800×1500 | 13,000.00 |
| RJZ-120-9 | 120 | 850 | 2 | Φ800×2000 | 13,500.00 |
| RJZ-150-9 | 150 | 850 | 2 | Φ1000×2000 | 13,800.00 |
| RJZ-180-9 | 180 | 850 | 2 | Φ1000×2200 | 14,100.00 |
| RJZ-200-9 | 200 | 850 | 3 | Φ1000×2500 | 14,600.00 |
| RJZ-250-9 | 250 | 850 | 3 | Φ1000×3000 | 15,800.00 |
| RJZ-300-9 | 300 | 850 | 2 | Φ1200×3000 | 15,500.00 |
| RJZ-190-9 | 190 | 850 | 3 | Φ1400×2000 | 14,800.00 |
| RJZ-210-9 | 210 | 850 | 3 | Φ1600×2000 | 16,500.00 |
Note: The above specifications are for reference only, furnace specific gall size is based on the demand for customized products.
