Help CenterDrying Furnace
Related Products
The furnace shell is made by angle steel and plate welded as cube. So the furnace is firm and durable. The shell is painted after anti-embroidered treatment.
2,Lining
The furnace lining is piled with lightweight refractory bricks named Mullite. Mullite is a kind of aluminum silicate and could use in very high temperature as 400°C. Compared with other refractory bricks, mullite is lighter and more stable. There are filld with full-fiber refractory insulation materials between the shell and lining to keep sealing and reduce heat loss.
3,Sealed furnace door
The sealed furnace door has the welded steel shell outer and full-fiber refractory insulation materials inter to keep seal and insulation. The door open/close with hand
4,Electrical heat elements
The electrical heat elements are silicone carbide sticks, placed the top and the bottom of the lining.
Feature:
When the parts become to heating, the hole furance is use to heating. After the heating treatment, you could take out the rods on the first small heat room for process and put in the new rods, the other rooms also left to keep heat. This program could alternately and efficiency.
| Item | Data |
| Furance modle | DLJ-55-60 |
| Rated power(kw) | 55 |
| Dinmention(mm) | 1300x1000x700 |
| Rated temperature(°c) | 400 |
| Loaded(KG) | 300 |
| Control system | 1 area,PID |
| Door | 6 small doors |
PIC:
