Help CenterRG Series Coaxial Cable(RG59with Power Cable,RG6,RG11,QR500)
Related Products
-
RG7 Coaxial Cable With 1.3mm Bare Copper, 5.7mm FPE and 8.1mm PVCNegotiableMOQ: 30 Kilometers -
RG59-S Coaxial Cable With 0.58mm Conductor, 3.66mm SPE BC Braiding and 6.0mm PVC JacketNegotiableMOQ: 30 Kilometers
-
RG11 Cable for TV, CATV and SAT TV NetworksNegotiableMOQ: 30 Kilometers
-
Coaxial Cable With 85% Velocity Propagation and 50 +/-2 Ohms Impedance (D-FB Series)NegotiableMOQ: 30 Kilometers
-
75-OHM-Coaxial Cable(3C-2V,5C-2V,RG59,RG6)NegotiableMOQ: 30 Kilometers
Specifications
Cable with lower attenuation, well waterproof performanceSpecification:
Center conductor: tinned copper, bare copper and copper clad steel available
Al-foil: non-bonded Al-foil, bonded Al-foil, double bonded Al-foil and double non-bonded Al-foil are available
Braiding wire: Al, bare copper and tinned copper available
Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15 and 0.16mm available
Braiding net: 32, 48, 64, 72, 80, 96, 120, 128, 144 and more available
Braiding coverage: between 30 to 100% available
PVC jacket of flame-retardant
Velocity of propagation: 85%
Packing:
Inner packing: wooden reel, plastic reel and paper reel available
Outer packing: carton box, pull out box and pallet available
Other packing available according to client 's request
Packing lengths:
100m/roll, 200m/roll, 305m/roll, 100 yard/roll, 200 yard/roll, 300 yard/roll
Other lengths available according to client's request
