Help CenterProfessional Manufacturers SFTP CAT7 Cable LAN Cable Computer Cable With CE and RoHS Approved Made in China
Related Products
-
Hangzhou Manufacturer High Quality UTP Cable CAT6 Computer Cable With Competitive PriceUS$ 0.12 - 0.36MOQ: 50000 Meters -
High Quality FTP CAT6 Cable Internet High Speed Lan Cable Network Cable Computer Cable China FactoryUS$ 0.06 - 0.38MOQ: 50000 Meters
-
Low Loss CAT5e UTP Cable Lan Cable Fluke Test Passed CE RoHS ApprovedUS$ 0.08 - 0.6MOQ: 60000 Meters
-
Hangzhou Manufacturer High Quality UTP Cable CAT5e Computer Cable With Competitive PriceUS$ 0.05 - 0.3MOQ: 60000 Meters
-
Cat5e UTP Cable With 23AWG Conductor 4pairs 15years ExperienceUS$ 0.08 - 0.38MOQ: 60000 Meters
1) Construction
Center Conductor:24 AWG BC/CCA
Dielectric: 0.90mm PE
Jacket: 5.20mm PVC
Nom. Thick:0.55mm
2) Characteristics
Temperature Rating:-20°C to 60°C
Dielectric Breakdown:2500V
DC Resistance/Unbalance:28.6Ω/1000 Max/5% Max
Characteristics Impedance: 100Ω
3) Other Electric Performance
Frequency (MHz)
|
Attenuation (dB/100m)
|
Return loss (dB/100m)
|
Pair to Pair | |
NEXT (dB/100m) | ELFEXT (dB/100m) | |||
0.77 1 4 8 10 16 20 25 31.25 62.5 100 155 200 300 350 | 1.80 2.00 4.00 5.80 6.50 8.20 9.20 10.40 11.70 17.00 22.00 28.10 32.40 41.00 44.90 | NA 20.00 23.00 24.50 25.00 25.00 25.00 24.30 23.60 21.50 20.10 18.80 18.00 16.80 16.30 | 70.00 68.30 59.30 54.80 53.30 50.30 48.80 47.30 45.90 41.40 38.30 35.50 33.80 32.30 30.20 | 69.00 66.80 54.70 48.70 46.80 42.90 40.70 38.80 36.90 30.80 26.80 22.90 20.70 17.20 15.90 |
Certificates: ISO9001, CE RoHS.
1. Your inquiry will be replied in 24hours.
2. 15 years Coaxial Cable's experience,can become your professional purchasing partner.
3. OEM&ODM, any your customized cables we can help you to design and put into product .
4. Sample you need so that to test our company 's ability, we are so glad to free offer it.
5. Protection of your sales area, ideas of design and all your private information is our duty.
Hangzhou LinAn LuHua Industrial Co.,Ltd is situated in Linglong Industrial Zone, Lin'an, Zhejiang , China, which is a capable enterprise with more than15 years experience both in the production and the management system.
We have the most advanced testing equipment, and we have got some authority certificate of this field, such as the ISO-9001, CE, ROSHS, all of these contribute to insure that we can provide the products with high quality. Our main products contains Coaxial cable, TV cable, Telecommunication cable, RF cable and Video cable, which has been widely used in the supervision system. According to their characteristics, they also can be divided into 2 types:1)RG59,RG6,RG7,RG11, 75 Ohm Coaxial Cable with Solid Polyethylene Insulation ,which is also named Vedio. cable;2)RG59,RG6,RG7,RG11, 75 Ohms Coaxial Cable with Gas-injected Foam Polyethylene Insulation, which is also named RF cable.
As the blueprint made by our company, we are going to enlarge our business on the existing market. Although the foreign trade is not prosperous as 10 years ago, we still attach great importance to the global market.
