Help Center15years Experience Low Loss 75ohms Coaxial Cable RG58 With 0.94mm Conductor in Telecommunication (CE RoHS)
Related Products
-
RG58 Coaxial Cable 75ohms 0.94mm BC/CCA/CCS Conductor CE RoHS ISO9001US$ 0.08 - 0.35MOQ: 50000 Meters -
Low Loss RG58 Coaxial Cable Jelly Filled With Competitive Price Hanghou ManufactureUS$ 0.08 - 0.35MOQ: 50000 Meters
-
Low Attenuation RG58 Coaxial Cable 50 Ohms Used in Telecommunication 15years Manufacture (CE RoHS)US$ 0.1 - 0.38MOQ: 50000 Meters
-
Low Attenuation RG58 Coaxial Cable 75 Ohms Jelly Filled CE RoHS Approved Competitive Price Hanghou ManufactureUS$ 0.08 - 0.35MOQ: 50000 Meters
-
Low Loss Coaxial Cable RG58 Jelly Filled CE RoHS Approved 15years ManufactureUS$ 0.08 - 0.35MOQ: 50000 Meters
2000 |
16.10 |
53.00 |
RG58 Series Drop Coaxial cable specifications
Physical Specifications
Nominal Dimensions |
Standard RG58 A/U |
Tri-shielding RG58 B/U |
Quad-shielding RG58 B/U |
Conductor |
0.94 mm( 0.037 in) |
19*0.18mm |
19*0.18mm |
Dielectric |
2.95mm(0.225 in) |
2.95mm(0.225 in) |
2.95mm(0.225 in) |
Shielding 1 |
Al /Pet foil |
Bonded Al /Pet foil |
Bonded Al /Pet foil |
Shielding 2 |
0.12mm*48 (40% coverage) |
0.12mm*64 (60% coverage) |
0.12mm*96 (90% coverage) |
Shielding 3 |
- |
Al /Pet foil |
Al /Pet/Al foil |
Shielding 4 |
- |
|
0.12mm*48 ( 40% coverage) |
Jacket |
4.95mm( 0.195 in) |
8.1mm( 0.319 in) |
5.35mm( 0.21 in) |
Messenger |
1.3mm (0.051 in) Zinc plated steel |
||
Mechanical Characteristics
Mechanical Breaking Strength of Messenger 0.051 inch 185lbs. 823 N
Electrical Characteristics
Impedance ( Ohms) 75±3
Nominal Capacitance (pF/m) 53
Velocity of Propagation 85%
Structural return loss (Db)≥ VHF 22
UHF 20
Attenuation [@68F.(20Degree centigrade)]
Frequency Mhz |
dB/100 ft |
dB/100 M |
30 |
1.90 |
6.30 |
50 |
2.46 |
8.10 |
150 |
4.30 |
14.10 |
220 |
5.20 |
17.10 |
450 |
7.50 |
24.60 |
900 |
10.70 |
35.00 |
1500 |
13.40 |
45.60 |
1. Your inquiry will be replied in 24hours.
2. 15 years Coaxial Cable's experience,can become your professional purchasing partner.
3. OEM&ODM, any your customized cables we can help you to design and put into product .
4. Sample you need so that to test our company 's ability, we are so glad to free offer it.
5. Protection of your sales area, ideas of design and all your private information is our duty.
Hangzhou LinAn LuHua Industrial Co.,Ltd is situated in Linglong Industrial Zone, Lin'an, Zhejiang , China, which is a capable enterprise with more than15 years experience both in the production and the management system.
We have the most advanced testing equipment, and we have got some authority certificate of this field, such as the ISO-9001, CE, ROSHS, all of these contribute to insure that we can provide the products with high quality. Our main products contains Coaxial cable, TV cable, Telecommunication cable, RF cable and Video cable, which has been widely used in the supervision system.
