Phenolic board machine with new technology
- 20 Set / Sets per Month
- Xingang China
- T/T
- Pneumatic spray machine Steel structure special multi-functional high pressure airless spray machine environmental protection and paint saving
- Concrete mixing station machine
- Gypsum block production line
- sale for Temperature plate slotting machine
- Welding rod production line equipment
- 8 hours 4-5 tons of electrode production line equipment
Product Details
Place of Origin: | Chile | Brand Name: | EPS | Model Number: | XL-FQ |
Product Description
Specifications
Phenolic board machineNew Technology with good productivity
New design to make phonelic foam perfect
Make by requirements
XL-FQ series Phenolic board machine production line is a professional machine for manufacturing sandwich panels of which the core material is phenolic foam and of which both layers is embossed aluminum foil or colored steel. The thickness of Phonelic board is 20-200mm, the width 1, 200mm and the length according to customers' requests. The Phonelic board are used as the air ducts in central air conditioning. The machine can used to make other insulation panel as long as the surface material is changed. The working principle of the machine is as below: Mix the raw materials with a certain ration in a container and then pour the mixture on the interlayer of the sandwich panel. Then the raw materials has the chemistry reaction of foaming and solidifying. In the end the automatic tracking cutting machine cuts the panels into a certain length.
Specifications:
1) the panel thickness scope : 20 – 70mm
2) Embossing aluminum foil thickness : 0.06 – 0.12mm
3) The core panel material density :60 – 65 kg/m3
4) Standard panel size : 4000 × 1200 mm (L×W)
5) Manufacturing speed : 1 – 4 m/min
6) Stirring speed : 4500 r/min
7) Installation power : 198 kw
8) The machine dimension : 45920×5365×3636 mm (L×W×H)
Applications: Used for producing PU and PF (phenolic poam) panels with aluminum foil on both sides or one side, PU and PF panels with colored steel or zinc-coated steel on both sides and other non-metal panels.
The components and its functions:
The components include: The aluminum foil embossing machine, the raw material distributor the aluminum foil/colored steel pre-heating installation, the material-baffling mechanism, the automatic tracking cutting machine, the roller supporters and brackets. All the components can be individually adjusted.
Delivery time: 60 days
Contact: Amanda
Mobile: 86-15032858558
