EMB4020 cnc desktop water jet granite cutting machine
CNC water-jet cutting machine is composed with cutting table, HP pump, CNC control system with cutting software, cutting head, Hp water valve, and sand controlling system. Also you can choose optional systems such as auto abrasive feeding system, water softening system and oil cooling system according your requests.
1.1 EMB2515 structure feature
1.1.1 Structure feature
- Casting beam and Y-axis base frame make it have excellent precision and stability.
- Table body and water tank which are sub aspect structure, lessen the pressure of sands and machined parts to moving parts.
- X-axis and Y-axis transmit to rolling nut ball screw mandrel.
1.1.2 Controlling system
We adopt the famous NAIKY controlling system and MITSUBISHI AC servo digit driving system and AC servo motor.
- 17”LCD liquid crystal display
- DNC on-line working function
- Functions of returning arbitrary point, bending, and circular arc working auto deceleration.
- Function of cutting figure imitation display.
- 160GB memory hard disk
- MITSUBISHI AC servo driver and motor.
-2GB memory card
- Multilingual function(Chinese English ,etc.,)
- Drive-by-wire and hand-hold controller, (optional parts, according to requests)
1.1.3 Chief technical parameter
- structure:Bridge
- cutting area
- X-axis:2500mm
- Y-axis:1500mm
- Z-axis:150mm
- repeatability:0.05mm
- X,Y speed:0-15m/min
- cutting accuracy:±0.1mm
power:220VAC, 60Hz, 3 phase 4 wire system (can be customized)
Remark: color can be made by customer ‘s requirement.
