Specifications
EMB3020 cnc water cutter machinecomposed with CNC cutting table
HP system
CAD/CAM software system
cooling system
CNC water-jet cutting machine is composed with cutting table, HP pump, CNC control system with cutting software, cutting head, Hp water valve, and sand controlling system. Also you can choose optional systems such as auto abrasive feeding system, water softening system and oil cooling system according your requests.
EMB3020 cnc water cutter machine structure feature
1.1.1 Structure feature
- Casting beam and Y-axis base frame make it have excellent precision and stability.
- Table body and water tank which are sub aspect structure, lessen the pressure of sands and machined parts to moving parts.
- X-axis and Y-axis transmit to rolling nut ball screw mandrel.
auto abrasive feeding system
cooling system
Technical data
No. |
Name |
Model |
Specification |
Remark |
1 |
EMB3015 CNC water jet (Bridge) |
EMB3015 (H2O) |
Max. pressure: 420MPA |
Standard |
EMB3015cutting table |
Cutting size: 3m*1.5m |
Standard |
||
EMM CNC control system |
Based on Windows with NC studio |
Standard |
||
2 |
Auto abrasive feeding system |
100L |
N/A |
optional |
3 |
Auto abrasive feeding system |
170L |
N/A |
optional |
4 |
Cooling system A |
|
N/A |
optional |
5. |
Cooling system B |
TCO-10A/1D |
N/A |
optional |
6. |
water soften system |
EMM-2000 |
2T/h |
optional |
7 |
Hand-hold controller |
N/A |
NAIKY |
optional |
8 |
Tools &Spare parts |
List 1&List 2 |
Free with the machine |
free |
9 |
Optional parts |
List 3 |
N/A |
optional |
