HT50B Aluminium CNC Punching Machine/ Number Punching Machine

US$ 100 - 100,000 MOQ: 1 Set

Key Specifications

Condition:

New

CNC or Not:

CNC

Power Source:

Hydraulic

Extreme Machinery Manufacture Co., Ltd. (Jingjiang)

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not CNC

Power Source Hydraulic

Place of Origin Jiangsu, China

Brand Name EMM

Model Number HT50B

Specifications

1. CNC punching machine
2. hydraulic hole punching machine
3.automatic punch press
4. number punching machine

HT50B turret punch press/cnc turret punch press/automatic punch press/ cnc punching machine

hydraulic hole punching machine automatic hole punching machine aluminium punching machine

TECHNICAL SPECIFICATIONS FOR HT50B

1	Type	HT50B
2	Punching force	300 KN
3	Max. punching diameter	Æ88.9 mm
4	Max. sheet size(One reposition)	1250×4000 mm
5	Max. sheet thickness	8 mm
6	Max. sheet weight	150 kg
7	Machining accuracy	±0.1 mm
8	Repeat positioning accuracy	±0.02 mm
9	Ram stroke	30 mm
10	Punching frequency	600 h.p.m
11	Max. positioning speed (simultaneous)	90 m/min
12	X-Axis traverse length	2000 mm
13	Y-Axis traverse length	1250 mm
14	Turret rotation	30 r.p.m
15	Number of tool stations (Including 2 index stations)	32
16	CNC system	FANUC Oi-PC
17	CNC system configuer	10.4²Color monitor RS232C interface 256K content
18	Main motor power	11 kW
19	Electrical energy(AC 380V )	30 KVA
20	Compressed air	0.2 m³/min 0.55 Mpa
21	Machine dimensions(approx)	4965×4400×2110 mm
22	Machine weight(approx)	18 tons
