Specifications
HT30A turret punchCNC hydraulic turret punching machine with high accuracy
Turret punchig machine :FANUC OI-PC
HT30A turret punch/cnc turret punch press/cnc hydraulic turret punch press
CNC hydraulic turret punch machine with high accuracy and efficiency has integrated most advanced technologies in the world. A perfect combination of newest control technology and conventional mechanism. It is ideal equipment in numerically controlled metal fabrication industry with good features such as high automation, high productivity, and stable feature, safe and reliable.
1 |
Model |
EMM HT30A |
2 |
Punching force |
300 KN |
3 |
Max. punching diameter |
Æ88.9 mm |
4 |
Max. sheet size(One reposition) |
1250*2500 mm |
5 |
Max. sheet thickness |
6 mm |
6 |
Max. sheet weight |
150 kg |
7 |
Machining accuracy |
±0.1 mm |
8 |
Repeat positioning accuracy |
±0.02 mm |
9 |
Ram stroke |
30 mm |
10 |
Punching frequency |
600/*900 h.p.m |
11 |
Max. positioning speed (simultaneous) |
112 m/min |
12 |
X-Axis traverse length |
1250 mm |
13 |
Y-Axis traverse length |
1250 mm |
14 |
Turret rotation |
30 r.p.m |
15 |
Number of tool stations (Including 2 index stations) |
32 |
16 |
CNC system |
FANUC OI-PC |
17 |
CNC system configure |
10.4²Color monitor RS232C interface 256K content |
18 |
Main motor power |
11 kW |
19 |
Electrical energy(AC 380V ) |
30 KVA |
20 |
Compressed air |
0.2 m3/min 0.55 Mpa |
21 |
Machine dimensions(approx) |
4965×2800×2110 mm |
22 |
Machine weight(approx) |
14 tons |
