Home > Manufacturing & Processing Machinery > Machine Tools > Grinding Machine > G74 Cylinder Grinding Machine
G74 Cylinder Grinding Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Surface Grinding Machine
CNC or Not:
Normal
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Type
Surface Grinding Machine
CNC or Not
Normal
Place of Origin
Jiangsu, China
Brand Name
EMM
Model Number
G74
Voltage
380V
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
G74 cylinder grinding machineG74 cylinder grinding machine
Technical data of G74
Working table |
Table size(L×W) |
mm |
1000×400 |
|
Max travel of table in longitudinal |
mm |
1100 |
||
Max workpiece to be ground(L×W×H) |
mm |
1000×400×400 |
||
T slot |
|
3×18 |
||
Table speed(stepless) |
m/min |
3-25 |
||
Max loading weight of table |
kg |
600 |
||
Wheel head |
Max distance from spindle to table |
mm |
575 |
|
Max travlel of spindle |
Transverse(Manual and hydraulic) |
|
440 |
|
vertical |
|
400 |
||
Spindle speed |
rpm |
1440 |
||
wheel size(O.D×W×I.D) |
mm |
Φ350×40×Φ127 |
||
Scale on the vertical hardwheel |
mm |
0.01 |
||
The wheelhead travel of the handwheel per circle of dial(vertical) |
mm |
1 |
||
Total power |
kw |
8.99 |
||
Spindle motor |
power |
kw |
5.5 |
|
speed |
r/min |
1440 |
||
Rapid up-down motor |
power |
kw |
0.37 |
|
speed |
r/min |
1440 |
||
Oil pump motor |
oil pump motor |
kw |
3 |
|
speed |
r/min |
960 |
||
Coolant pump motor |
coolant pump motor |
kw |
0.125 |
|
speed |
r/min |
2800 |
||
flow |
L/min |
100 |
||
