EMM30-282 steel profile metal cold roll forming machine
No | Item | Parameter | Remark | |
1
| Material | Type | cold-rolled strip |
|
Thickness(mm) | 1.5-2.0 |
| ||
Yield strength (Mpa) | 235-345 |
| ||
Width (mm) | As the detail drawing |
| ||
2 | Rolling speed(m/min) | About 20-25 | not include the cut off time | |
3 | Forming machine main power (KW) | 11kw | For reference | |
4 | hydraulic pressure station (KW) | 5.5 | For reference | |
5 | Uncoil motor power(kw) | 3kw | For reference | |
7 | Main power | 39.5 | For reference | |
8 | Power | AC220V,60Hz,3phase |
| |
9 | Machine size | About 8.×1.6×1.3 | For reference | |
Technological process
Electrical uncoil – guid feed- roll forming – cut to length – finish product
1. uncoil system
Loading : 3 T
Coil inside diameter : φ508mm
Coil width : 400mm
Coil outside diameter: φ1350mm
Feeding motor : 3Kw
We assist customers in well understanding the product information like features, functions and applications and so on. As for the detailed procuring information or drawings, our professionals will first conduct a careful examination and then recommend the most suitable machines or devise proper schemes for customers. We also provide free samples if necessary.
After-Sale Service
1. One year warranty is provided.
2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the
warranty, we only charge for the basic costs of parts.
3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.
